ZIP·A·DOO Playfield
Chart
n
9
3
193
RUBBER RINGS
D im ensi onsare ins ided iameters .Numbers in
paren thesesind ic ate qua n tity used ,if in excess
o f
One.
A R ·115 ·4,Rebound
B
R ·521 ·2 ,lY> in .(3)
C
R ·52 1 -3 ,2 in .
(2)
D
R -521 -4 ,
2Y,
in . (3)
E R -392 ,
15/16
in.
F R -52 1 ·5,3 In . (3)
G R -52 1 ·6 .3% in .
H
R- 406 ·3 ,Yellow (2)
R ·243 ,
5/16
In. (3)
PARTS
1
Top Arch .. ....• ....
P-5839 ·49
2
Bottom Arch
P-5871·38
3
Shooter Gauge ,
P-6359 ·10
4
S ide Rail , Left
A·2900 -25
5
Side Rail, R ight ..•.. ...
A-2900-20
6
Ball Aebo ._.ndAny .....
AS-493-3
Detailed under item 6, page 185
7 Ball Gate
&
Swit ch Assy .
AS·1315 -5
Detailed unde ritem 7 , page 187
8
Bal lGate Cover
P·2996·1
9
Light Sh ield & Bush ing ..
A·2890 ·59
10
Bumpe rCap, Red
C-719·1
11
Bumper Cap, Green
,
C-719-4
12
Mushroom Bumper, Gre en
AS-2291·4
Cap ,Green
'..
C-616-4
Eye let
_
M-122-13
Post . _
_
C·617-8
Reta ining R ing . _. _ ..
P·2891-4
Rubber R ing .. _.•...
R·392
Spring Compre ss ion
SP-200-162
13
Ball G a te
&
Wire
_
AS·2250 -12
Brac ket
,
P·5867· 2
Wire _..•...
_
_.
M-1272-11
14
F lipper, W hite
_..
C·611-5
15
Bu m pe r
,.... .
C·Sl0
COMPL ETEASS Y•• PAG E254
16
Wire Rollover .•. ....
M-1336-9
17
Wir e Ro llov e r
M-1336-10
BRACKETS FOR 16 ,17 :
SEE PAG E275
SWITCH ESFOR 16, 17 :
SEE PA GES 36 , ETC ..
18
Ba llGu ide Rail
P·6495·63
