SNAP-OUT SCORE COUNTER UNITS
I
SEE NOTE A, B
I
CONTACT PLATE ASSY.
A-2212-7
WIPER ASSY.
(NOT VISIBLE)
A-1618-3
Not used in AS-1900-9.3,
AS-1900-104
ROCKER ARM
C-703-1
SWITCH
In
AS-190D-93,
AS-190D-94:
ASW-M-300-1
In
AS-1900-95:
ASW-M-200-1
In AS-1900-1 04, AS-1900-1 05 :ASW-M- 300-1
In
.1\$-1900-'
06:
ASW-M-
200-1
COIL
CO-29·1600
ROLL PIN
P.1637-43*
S-496·160*
PLUNGER
Drive
Pawl Assy.
FASTENERS
SP·100-121
SPRING
P-6813
REEL LOCK
A-2214-20
BASE PLATE ASSY.
Order fasteners (nuts,
screws,
washers,
erc.)
by
name
or description with reference
to
(a) name of part which
fastener
secures,
(b) Score
Cou nter,
(c)
name
of
game.
. *Slored
components
of AS-2293-S
May be purchased separate ly.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
169
