Page 104 - 1973_BALLY PARTS CATALOG ASPIRE

SPRING RATCHET SPRING
SP-l00-110
BASE PLATE
See page 160
SECURED BY
PIVOT PIN
S-737 -48
AND
ELASTIC
STOP NUT
M-319-3
RESET
PLUNGER
S-496-101
ESCAPEMENT
PAWL
C-342
P-ll
SPRING-WASHER
(Nat Visible)
CORE PLUG ASSY.
A-613-33
Operate Reset Plunger by hand until Rat chet resets
to zero posi tion, i.e., until rese tting movement stops.
Then oper ate Step-up Plunger and, while holding
Step-up Plunger in, check to see that Reset Pawl rests
at base of ratchet-tooth (point at which straig ht and
angular edges of tooth meet ). If Re se rP awl is not at
base of tooth, adjust Spring- Stop (P-3384) until Rat-
chet moves into posi tion to Perm it Pawl properly to
engage tooth, as described. Then check unit manual-
ly by operating Step-Up Plunger. Afte r Reset Pawl
drops into position described above, Step -up Arm
should over-ride approxi mately 1/64 in. before being
stopp ed by Step-Up Arm Stop ("ear" formed in Base
Plate) . Bend Stop one way or another to redu ce or in-
crease over-ride to approximately 1/64 in. Reser Pawl
shou ld then properly drop into base of toot h, without
binding, when Reset Plunger i-s lightly ope rated (with-
out pu sh ing Plunge r a I I the way in).
rORSION SPRING
SP-370
WIPER ASSY.
SWITCH
(IF USED)
See page 160
CONT ACT -PLA TE
(WIRED)
See page 160
WASHER FOR
WIPER ASSY.
P-801-107
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
159
