JOUST Playfield
Chart
o
d
• E 0
0
0
0
0
0
0
®®@
000
000000
0
®;[~
@
() 0 0
0
0
000
0
®@@
o
I
o
o
0
0000
000
•
I
o
2
3
157
RUBBER RINGS
Dimensions are inside diameters .
Numbers in
parentheses indicate quantity used,
if
in excess
of one.
A R -115-4 (Rebound)
B R 137-2,
3/4
in. (4)
C R -521-2, 1
Y,
in. (3)
o
R -521 -3 ,2 in .
E R -243,5/16in.(3)
F R ·521-4, 2% in.
G R -521-5,3 in. (4)
H R
·392,
15/32
in. (4)
J
R-l08-3 (Shooter Tip)
PARTS
1 Top Arch
P-5839 -50
2 Bottom Arch
. P-5871-38
3 Shooter Gauge .. .......
P -6359 -10
4 Side Rail, Left
P-6360-33
5 Side Rail, Right
.. A-2900-20
6 Ball Rebound Assy
AS-493-3
As detai led, item 6, page 156
7 Ball Gate
&
Switch Assy.. AS-1315 -4
As detailed, item 7, page 156
8 Light Shield & Bu shings.. A-2890-51
9 Mushroom Bumper, White AS-2291-2
As detailed, item 13, page 156
10 Mushroom Bumper, Red .. AS-2291-1
Cap
&
Plunger, Red .... C-616-1
Eyelet
. M-122-13
Post
C-617-8
Retaining Ring
P-2891-4
Rubber Ring
R-392
Spring ,Compression SP-20(}-162
11 Mushroom Bumper, Yellow AS-2291
Same as item 10 , above, excepting
Cap
&
Plunger, Yellow. C-616-3
12 Flipper
&
Pin Assy
AS-2214-14
Flipper, Orange
C-610-11
Flipper Arm Assy _.. A-2747-4
Screw, Shakeproof,
Type 25,
Self -Tapping,
Cadmium Plated
_No.6x% in,
13 Rollover Wire
M-1336-2
14 Rollover Wire
M-1336-3
15 Rollover Button
C-387-5
16 Bumper Cap ,Red
C-719-1
17 Bumper Cap, Yellow C-719-3
18 Gate Wire
M-1335-1
19 Top Gate Assy
AS-2250-20
Gate Assy
A-3339
Wire
M-1272-11
20 Exit Gate Assy
AS-2250-11
Bracket
P-5867-7
Wire
_. ,
M-1272-8
5
