ANTI·TILT COMPONENTS
-Front Door
KING REX and earlier games*
AT LOCK END OF DOOR
TILT SWITCH & BRACKET ASSY AS-982-258
Back-up Plate P-126-473
Bracket P-126-29
Insulator P-150-77
Screw, Parker Kalon,
RoundHead,
Sheet Metal, .
Type Z (2 used) No. 4x7/8 in.
Speed Nut, Twin Type P-483
Switch ASW-A20
Switch Plate (Spring) P-137-5
AT CENTER OF DOOR.
TILT SWITCH & BRACKET ASSY ....•. AS-982-722
Same as AS-982-258, above, excepting
Screw, Parker Kalon,
Round Head,
Sheet Metal,
Type Z (2 used) No. 4x3/4 in.
Switch ASW-Al
GALAHAO*
TILT SWITCH & BRACKET ASSY AS-982-754
Same as AS-982-28, above, excepting.
Bracket P-126-185
Switch ' ASW-A20
CAMELOT and later games*
TILT SWITCH & BRACKET ASSY AS-982-762
Back-up Plate P-126-473
Bracket P-126-185
Insulator P-150-77
Switch ASW-A20
Switch Plate (Flat) , , P-126-154
Illustrated, page 129
Switch Plate (Spring) P-137-5
Switch Screw (2 used) MS-540-14-110
*See chronological list of games, page 6.
Mounting Board
TILT SWITCH & BRACKET ASSY AS-982-258
As detailed under Front Door at left
Playfield
BRACKET -~
P-126-408
TILT-SWITCH & BRACKET ASSY.
AS-982-460
WHEN ORDERING PART I SPECIFY PART NO. AND NAME OF GAME
