STEPPING UNITS, FULL RESET
Effective with GATORand later games*, game to game variations in Full Reset
Stepping Units are described on this page.
If port number is not known for variable components in OP-POP-POPand earlier
games*, order by nome with reference to (0) nome of Unit, (b) nome of game.
Order nuts, screws, washers by nome with reference to
(0)
nome of Unit,
(b) nome of game, (c) port fastener secures
FASTENERS
GAIOR
ON BEAM
Ball Count Unit
As illustrated,
page 128, with
Base Plate Assy.
A·1768
Coil, Step-up
B-27-1300
Contact Plate (wired) . . ..
W-l043-1
Plate. . . . . . . . . . . . . . . ..
P-126-154
Illustrated below
P 126·154
Ratchet
&
Shaft . . . . . . ..
C-l050-4
Spring, Extension (2 used) SP-l00-113
Step-up Arm Assy.
A-1765-8
Switch,
End of stroke
ASW-Ul0
Zero
SW-011-33
Switch Mounting Bracket.
P-126-247
Switch Plate (spring)
P-137-5
Wiper Assy.
AS-l046-464
Coin Unit
Same as Ball Count Unit, with
Coil, Step·up
B-26-1100
Contact Plate (wired)
W-92381
Ratchet
&
Shaft.
. . . . . ..
C·l050-3-36
Ratchet Pin
M-740
Step-up Arm Assy
'
A 1765-4
. Spring, Extension (2 used).
SP 100-120
Switch,
Limit.
. . . . . . . . . . . . ..
SW-011-33
Zero,
Build-up (no blade) ..
ASW-UO
Break Switch
ASW-U2
Wiper Assy.
AS-l 024-1 08
Player Up Unit
Same as Ball Count Unit, with
Coil, S'tep-up
B-26-1100
Contact Plate (wired) . . ..
W-l004·22
Spring,
Extension,
Reset
SP-l00-120
Step-up
, SP-l00-113
Retaining
SP-433-1
Switch
NOT USED
Wiper Assy.
AS-l 046-554
*
See chronological
list of games, page 6.
Ball Count Unit
As illustrated,
page 128, with
Base P Iate Assy. .
.
Coil, Step-up
.
Contact Plate (wired)
.
A-1768
B-27-1300
W-l043-10
P-126-154
BALLYHOO
Coin Unit
Same as Ball Count Unit, with
Coil, Step-up
B-26-1100
Contact Plate (wired) . . ..
W-923-81
Ratchet
&
Shaft.
. . . . . ..
C-l050-3-38
Ratchet Pin
M-740
Spring, Extension (2 used) SP-l00-120
Step-up Arm Assy.
A-1765-4
Switch
SW-120-55
Wiper Assy
AS-l024-108
Player Up Unit
Same as Ball Count Unit, with
Base Plate Assy
A-1768-42
Bushing (Contact Strip Assy)S-231-332
Coil, Step-up
B-26-1100
Contact Plate (wired) . . ..
W-923-197
Contact Stri p Assy.
A-1119-77
Spring,
Extension,
Reset
SP-l00-120
Step-up
SP-l00-113
Retaining
SP-433
Switch
SW-l00-472
Wiper Assy
AS-l046-599
KING IUT
Ball Count Unit
As illustrated,
page 128, with
Base Plate Assy.
A-1768
Coil, Step-up
B-27-1300
Contact Plate (wired)
W-l043-11
Plate
P-126-154
IIIustrated at left
Ratchet & Shaft . . . . . . ..
C-l050-4
Spring, Extension (2 used) SP·l00-113
Step-up Arm Assy. . . . . ..
A-1765-8
Switch,
End of stroke
NOT USED
Zero
SW-l00-372
Switch Mounting Bracket.
P-126-247
Switch Plate (spring) ....
P-137-5
Wiper Assy. . . . . . . . . . . ..
AS-l046-600
KING
REX
Ball Count Unit
Same as Ball Count Unit, KI NG TUT, with
Contact Plate (wi red) .....
W-l 043-12
Ratchet
&
Shaft.
. . . . . ..
C-l050-5
Wiper Assy
AS-l046-606
Plate
III
us trated at 1eft
Ratchet
&
Shaft
Spring, Extension (2 used)
Step-up Arm Assy. . .....
Switch,
End of stroke
.
Zero
.
Switch Mounting Bracket.
Switch Plate (spring)
.
Wiper Assy
.
C-l050-7
SP-l00-113
A-1765-8
ASW-U20
NOT USED
P-126-247
P-137·5
AS-l046-552
CONTINUED
ON
NEXT PAGE
WHEN ORDERING PART,
SPECIFY PART NO. AND NAME OF GAME
129
JOUST
Player Up Unit
As illustrated,
page 128, with
Base Plate Assy.
A-1768
Coil, Step-up
B-26-1100
Contact Plate (wired)
W-l004-43
Plate
P-126-154
IIIustrated at left
Ratchet
&
Shaft . . . . . . ..
C-l050-14
Spring, Extension (2 used) SP-l00-113
Step-up Arm Assy
A-1765-4
Switch,
Build-up (no blade)
ASW-UO
Break Switch
ASW-U2
Switch Mounting Bracket
P·126-247
Switch Plate (spring)
P-137-5
Wiper Assy
AS-l046-573
BALLYHOO
Ball Count Unit
As illustrated,
page 128, with
Base Plate Assy.
A-1768
Coil, Step-up
B-27-1300
Contact Plate (wired) . . ..
W-l043-1
Plate.
. . . . . . . . . . . . . . ..
P-126-154
Illustrated at left
Ratchet
&
Shaft
C-l050-4
Spring, Extension (2 used) SP-l00-113
Step-up Arm Assy.
A-1765-8
Switch,
Build-up (no blade) . . ..
ASW-UO
Break Switch
ASW-U2
P-126-247
P-137-5
AS-l046-464
Switch Mounting Bracket.
Switch Plate (spring)
.
Wiper Assy
.
