Page 57 - Bally 1971 Parts Catalog

SCORE MOTOR ASSYS.
HEXAGON
SHAFT
10-11 CAMS
S-1947
12-13 CAMS
S-1947-5
FRONT VIEW
WASHER
(3 USED)
r------ P-801-102 I---~
P-6698
SIDE PLATE
RETAINING RING
AT EACH END OF
HEXAGON SHAFT
P-2891-8
P-6698-1
SIDE PLATE
SPACER SPRING SUPPORT BRACKET
S-1949 (COMPRESSION) 10-11 CAMS: P-6629-2
SP-20D-31
12-13 CAMS: P-6629-43
TOP VIEW SWITCH
BRACKET
10-11 CAMS
P-126-537
P-6316-4
RETAINING RING
E-119-354
MOTOR
SEE NOTE C
HINGE MOUNTING BRACKET
P-6629-8
NYLINER
C·537·5
$·739·171
ROD
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
