Page 134 - Bally 1971 Parts Catalog

SLING-SHOT KICKER ASSYS.
SWITCH PLATE
P -137-5
~-MS-540-12-110
SCREW
KICKER ARM ASSY.
I SEE PI r;E/2111
SWITCH
ASW-A10-l-
(MAKE SWITCH)
BRACKET
P-126-471
1
LASTIC
C-342 STOPNUT SWITCH & BRACKET ASSEMBL Y**
GUIDE RING M-319-2 (AS-982-S09)
SWITCH & BRACKET ASSEMBL y**
(AS-982-S61 )
Identical to AS-982-S09, above, with positions of
Bracket and Switch Plate reversed,
I ALSO SEE PAGE 1211 I
CORE PLUG ASSY.
A-613-67
SWITCH ADJUSTMENT NOT E
NO.8 X 3/8 SCREW
PARKER KALON
SWAGE FORM
(4 USED)
When Sling-Shot Kicker is at rest, actuating blade of
Switch should just barely touch Rubber Ring, with
1/16 in, air-gap between switch po int s,
* See chronological list of games, page 6.
* * Used with Rebounds and Slingshots.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
