Page 132 - Bally 1971 Parts Catalog

FLIPPER·ZIPPER: RELATED PARTS
FLIPPER & PIN ASSYS.
Left AS-2214-7
As illustrated, page 202, with
Flipper . . . . . . . . . . . . . . . . . . . . . . . . .. C-609-5
Flipper Arm Assy A-2747-4
Right AS-2214-6
Same as AS-2214-7, above, excepting
Flipper C-610-5
IMPORTANT
Although above Flipper & Pin Assys. are normally used
with Flipper Zipper, check pages commencing with page
203 for possible game to game variations.
FLIPPER BUTTON ASSY.
See page 202
RUBBER RINGS
See Play field Charts, commencing page 156
SWITCH & BRACKET ASSY AS-982·588
Bracket . . . . . . . . . . . . . . . . . . . . . . . . . . .. P-126-548
Switch,
Break . . . . . . . . . . . . . . . . . . . . . . . . . .. ASW-A2-39
Make-Make. . . . . . . . . . . . . . . . . . . . . .. ASW-A 11-3
Switch Plate (Spring) P-137-5
Switch Screw (2 used) MS-540-20-510
IMPORTANT
Although above Switch & Bracket Assy. is normally used
with Flipper Zippers, check pages commencing with page
203 for possible game to game variations.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
208
