4 QUEENS
Playfield
Chart
I ,
I®I
I ,
I I
I
I
111 \
0
I ,
\
\
'I> '
,
,
I
\ .
23
o
23
o
22
o
o
0°0 0
o o
o
~
17
2
CJ
RUBBER RINGS
Dim e nsions are inside diameters.
Numbers in
parenth eses indicate quantity used,
i f
in excess
of one.
A R -115 -4(Rebound)
B R -521 -2,lY,in.(3)
C R -5211, 1 in. (7)
D R -521 -5 ,3 in . (5)
E R -521 -4,
2Y ,
in.
F R -2 43 ,5 /16 in . (10)
PARTS
1 Top Arch
P-5839-57
P-5871 -38
P-6359-10
CA-1208-2
CA-1208-1
2 Bottom Arch
.
3 Shoo ter Gauge
_ .
4 S ide Ra il, Left
.
5 Sid e Rail, Right
.
7
6 Inner Rail.
CA-1208-4
7 Pro tective Angle
P-7639
8 Ball Rebound
AS-493-3
Bracket . . . . . . . . . . .. P-318-3
Bu shing
S-231-99
Nut
N-l024 -1111
Rubber R ing. . . . . . .. R-115-4
Sc re w,Hexagon Head
No .1
0-24
X
% in .
W asher
P-1901
9 Ba ll Gate Assy
A-1475-1
10 Ba ll Gate Co ver
P-2896-5
11 Light Sh ie lds
A -2890-87
12 Bumper Cap, Blue
C-719-18
13 Bumper Cap, Yellow
C-719-17
14 Rollover Button
C-387-5
BUSHING FOR ABOVE .. S-1559-1
PUSH-ON FASTENER FOR
ABOVE
M-298-9
SWITCH FOR ABOVE
ASW -AI-4
SWITCH STOP BRACKET FOR
ABOVE
P-126-562
WA SHER FOR ABOVE
P -801-125
15 Flipper & Shaft Ass v,Right AS-2214-6
Flipper
C-610-5
Flipper Arm Ass y
A-2747 -4
Sc rew ,Shakeproof, Type 25 ,
Self -Tapping,
Cadm iumPlated .. .
No, 6 x
'h
in,
16 Flipper
&
Shaft Assy, Left AS-2214-7
Same as item 15 above exceptin g
Flipper
C-609-5
17 Rollover Wire
M-1336-2
18 Ro llover Wire
M-1336-3
19 Rollover Wire
M-1336-10
BRACKETS FOR ABOVE: SEE
PAGE 222
SWITCHES FOR ABOVE: SEE
PAGE 101 , ETC.
20 Guid e Rail, Red
C-693 -1
21 Guid eRail , Red . . . . .
C-694 -1
22 Mu shroom Bumper ,Wh ite AS-2291 -2
Cap
&
P lunger, White .. C-616-5
Eyelet
M-122-13
Post
C-617-8
Retaining Ring
P-2891-4
Rubber Ring
R-392
Spring, Compression .. SP-200 -162
PAL NUT FOR ABOVE.
M-1314-2
SWITCH FOR ABOVE: SEE
PAGES 101, ETC.
23 Ta rge tAssv , Red
.
Bra cket
.
Pl a te
.
Switch Sc re w(2 used )
Switch Plate (Spring )..
Ta rg e tSwitch Assy ...
AS-982-794
P-126-471
P-126-155
MS-540-110
P -137 -5
A-3359-4
o LIBERAL POSITION
• CONSERVATIVE POSITION
