TRAIL DRIVE Playfield
Chart
10
I
1
I
1
1
"
10
h
,-Y
13
o
13
<0
13
o
o
00
°0
oo
o
o
LIBERAL
CONSERVATIVE
RUBBER RINGS
Dimensions are inside diameters.
Numbers in
parentheses indicate quantity used,
if
in excess
of one.
A R -115-4, Rebound
B R -521-5, 3 in . (4)
C R -521-2, 1Y ,in. (3)
0
R -521-9,5 in.
E R -521-4, 2Y, in.
F
R -521-3, 2 in.
G R-521-1,1 in.
H
R ·406·3, Flipper (2)
PARTS
1 Top Arch
2 Bo ttom Arch .
3 Shooter Gauge .
4 Side Rail, Le ft
, ..
Guide Rail ..
Screw Nail
.
Side Rail
.
5 Sid e Rail , Right
.
6 Pr o tective Angle ..
7 Ba ll Guide Rail ..
8 Ba ll Gate Assy
.
P-5839-55
P-5871-38
P-6359-10
AS-2590-1
P-6244-48
M-330-3
CA-1208-2
CA-1208-1
P-7839
P-6495-67
AS-1315 -5
Detail edunder item 7, page158
9 Ball Gate Cover. . .
P-2996-1
10 L ight Shi e lds ... ..
11 Bumper Cap, Red
12 Bumper Cap, Green
13 Rollover Button.
BUSHING FOR ABOVE ...
PUSH -ONFASTENER
A-2890-63
C-719-12
C-719-13
C-387-5
S-1559-1
M-298-9
SWITCH FOR ABOVE. . .. ASW-A1-4
SWITCH STOP BRACKET P-126-562
WASHER FOR ABOVE
P-801-125
14 Flipper, White. .
C-611-5
15 Ball Gate
M-1335-1
DETAIL OF GATE ASSY.
SHOWN ON PAGE 194
16 Rollover Wire
" M-1336-2
17 Rollover Wire
M-1336-3
BRACKETS FOR ABOVE:
SEE PAGE 222
SWITCHES FOR ABOVE:
SEE PAGE 101, ETC.
18 Ball Gate & Wire
AS-2250-24
Bracket. . . . . . . . . ..
P -5867-12
Wire . . . . . . . . . . . ..
M-1272-17
19 Ba ll Rebound Assy .. .. .
AS -493-3
5
Detailed under item 6, page 156
20 Mushroom Bumper, White AS-2291-2
Detailed under item 13, page 156
21 Guide Rail, Red
C -701-1
22 Rollover Wire
M-1336-10
ALSO SEE PARTS LISTED
UNDER ITEM 17 ABOVE
©
13
2
3
165
