SCORE MOTOR ASSYS.I
SEE NOTE AI
CAM ASSY.
SEE NOTE A
o
SCORE-MOTOR PARTS
Gear-Box Assembly
ZGB-2526-8
(Consists of Gear-Box and 3 Gears
listed below)
Gear, First.
........•...
M-G-4109-1
Gear, Intermediate
(Doub Ie Gears)
M-G-5818-1
Gear
&
Shaft ••.....•..•.
ZGS-2526-8
Rotor & Shalt ..•••.....
ZRST-1715-33-1
Stator (Motor E-119-315)
•• . •.
ZS-2503-256
Stator (Motor E-119-332) ••••••
ZS-2S03-261
Stator (Motor E-119-336)
ZS-2S03-258
NOTE A
If part number
IS
not listed in SPECIFIC PARTS
DATA, commencing on page 8, order part by name,
specifying name of game.
Score Motor Assy. illustrated was used with modi-
fications noted at right in Bolly flipper.type games
through
TRIO
(Add·A.Ball Model)*. New Score Motor
Any. appears on pages 105, 106.
() ()
MOTOR
SEE NOTE C
NOTE B
Base-Plate A-2722 and Base-Plate A-2722-1 may be
used interchangeably in any Bally flipper-type game
through TRIO (Add-A-Ball) model.
NOTE
C
E-119-31,s (60 cycles) and E-1l9-332 (50 cycles) in
3-IN-LINE and earlier games".
E-119-336,
which may be operated with either 50
or 60 cycles current supply,
was used in HOOTE-
NANNY and later games through TRIO (Add-A-Ball
Model)" and is recommended replacement for E-1l9-315,
E-1l9-332. (Motor number is marked on Motor.)
Motor E-119-345 is not available,
should be replaced with Motor
E-119-336,
components of which
may be separately purchased.
.s..
chronolotical lisl 01to",.',
po,.
7.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
104
