Page 92 - Bally 1969 Parts Catalog

(SEE NOTE AA
COIL
SEE NOTE A
P-1158-9
SPRING WASHER
A-31~28
SWITCH
& BRACKET
ASSY.
SEE NOTE C
S-458-20
RESET-ARM
AND LINK
SEE NOTE B
3/32 in. by Y2 in.
COTTER PIN
HOTE A
I( part number not listed in SPECIFIC PARTS DATA,
commencing on page B, order parr by name, specifying
name of game, number of relays in bank, name of Relay.
(When ordering Switch for Relay with 2 Switches, be
sure to specify L EFT OR RIGHT to indicate rel ati ve
position of Switch, looked at from lug side of Switche s.)
NOTE AA
Components illustrated used in CAPERS-
VILLE and earlier games'.
Motorized Trip Relay used in ROCKET
III and later games * shown on pages
101, 102.
RELAY COILS
AND SWITCHES
SEE NOTE A
LS-832-4-510 ,--------,
RESET-SHAFT
SEE NOTE A SP-19~2 (Clear)or
SP-19~3 (Red)
TIE-ROD
SEE NOTE A
RESET-ARM
AND
SPRING STUD
SEE NOTE C
HOTE B
In 50/50 and earlier garne s ", A-I290-6 for LEFT end
of bank, looked at from lug side of Switches; A-1290-7
for RIGHT END.
In ACES HIGH through CAPERSVILLE*
Reset Arm & Link Assy.
LEFT END ••................ A5-2373
Arm Assy., Reset A-12B9-15
Cotrer Pin 3/32 in. by 1/2 in.
Link P-2239
J Washer P-BO 1-145
RIGHT END AS-2373-1
Same as AS-2373, EXCEPTING
Arm Assy., Reset A-12B9-16
HOTE C
If part number not listed in SPECIFIC PARTS DATA,
commencing on page 28, order parr by name, specifying
name of game, number of relays in bank.
• See chronological Ii., 01 gom•• , pog. 7.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
99
