NUMERICAL PARTS LIST
S·1962·SERtES Tie Rod, Reset Assys., Z·1l54·2 Frame, Interlock Relays
Motorized Trip Relays Z-1154-3 "
S·1968 Cam Shaft, Reset Assys., Z·1l60 Armature Plate, "KK" Type Relays
Motorized Trip Relays z.u 61 Frame, "KK" Type Relays
S·196S.SERIES " Z-1161- 1 "
S·2032 Coupling, Z·l170·SERIES Switch, "KK" Type Relays
Orbit Unit AS-2380-34 ZGB·2526·8 Gear Box Assy.,
SP·SERIES Spring (V) Motors E·119-315, E·119·332, E-119-336
SS·~-28·4·1 107 Set Screw ZGS-2526·8 Gear & Shaft,
SS·1032·4·1tt4 •• Motors E·119-315, E·119-332, E-119·336
SW-SERIES Switch (V) ZRST·1415·31·9 Rotor & Shaft, Motor E·119-354
T·362 Switch, Relay ZRST·t715·33·1 Rotor & Shaft,
Cable E-556-297 Motors E·119·315, E·119·332, E·119-336
W·SERIES Contact Plate (Wi red) (V) ZS-1707·2531 Stator, Motor E·119-354
WS·8·8·510 Screw, Wood ZS· 2503· 256 Stator, Motor E·119-315
Z-149·K Frame Assy., Magnet Assy. E·101·95 ZS-2503·258 Stator, Motor E-119-336
Z·187·9 Armature Assy., Magnet Assy. E-101-95 ZS·2503·26l Stator, Motor E-119·332
Z· n 50- SERIES Switch, "KK" Type Relays
(V) See various components described in General Ports
Catalog, commencing page 82, and Specific Parts
Data for specific games, commencing page 8.
J
J
J
J
J
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
173
