NUMERICAL PARTS LIST
8-326
Screw. Hexagon Head, Interlock Relays;
C-708
Pawl, Hold, Score Counter Units
"KK" Type Relays
C-709
Switch Actuator (V)
C-100-SERIES
Ratchet & Shaft IV)
C-709-1
"
C-114
Body. Standard Bumper Assys.
C-717
Button, Push Button Assy. AS-2443
C-114-3
Body, Thumper ,Bumper Assy.
C-718
Button Housing,
C-115-l
Base, Bumper Assys.
Push Button Assy. AS-2443
(Excepting Mushroom Bumper Assys.)
C-719
Cap, Thumper Bumper
C-117
Post, Plastic, Triangle (Specify color)
(Specify colors, marking)
C-119-2
Post, Plastic, Short (Specify color)
C-720-5-8
Number Wheel, Score Counter Units
C-119-15
Post, Plastic, Long (Specify color)
C-726-SERIES
Coin Entry Insert
C-12l
Post, Plastic, Diamond (Specily color)
See International
Coin Mechanism Data,
C-122
Ball Guide (Specify color)
commencing page 87
C-27l-SERIES
Clip (V)
C-769
Switch Actuator (V)
C-342
Guide Ring (Plunger)
C-769-SERI
ES
"
C-387-5
Rollover Button
C-l050
Ratchet & Shaft (V)
C-387-6
"
C-1050-SERIES
"
C-434
Ratchet & Shaft (V)
C-1051
"
C-434-5
"
C-l060
"
C-435
Pawl, Drive Pawl Assy. AS-2293-1
C-1060-SERIES
"
C-435-SERIES
Pawl, Drive Pawl Assy. (V)
C-2794-304
Coil, Magnet Assy. E-I01-95
C-436-3-8
Number Wheel, Score Counter Units
C-7800- SERIES Coil
C-537-SERIES
Nylmer (V)
CO-SERIES
Coil (V)
C-578
Button, (Button Switch);
E-101-95
Magnet Assy., FlipperZippers
Kicker Button (Specify color)
E-101-43
Resistor, 15 ohms, 5 walls
C-583
Bushing (Bounce Switch)
E-108-87
Switch, Coin Switch Assy. AS-IB9B-lt
C-609-5
Flipper Cap,
E-108-88
Switch, Coin Switch Assy. AS-IB9B-12
C-609-6
"
E-108-98
Switch,
C-610-5
Flipper Cap,
Coin Switch & Rejector Mounting Assy.
C-610-6
"
AS-277-97
C-615
Lamp Shield (Specify
colon
E-108-103
Micro Switch (Mystery Bonus, GOLD RUSH)
C-616-3
Cap & Shall. Mushroom Bumper Assy.
E- 119 - SE R IE S Motor (V)
(Specify color)
E-120-SERIES
Lamp Socket
C-617·8
Post, Mushroom Bumper Assy.
E-122-95
Transformer
(Specify color)
E-125- SE RIES Lamp
C-635
Cap, Standard Bumper
E-130-10
Counter, Total Play
(Specify color. marking)
(Often designated as Meier)
C-649
Bearing, Nylon (V)
E-133-SERIES
Fuse
C-649-SERIES
"
E-136-17
Connector, Female
C-664
Button (Button Switch) (Specify color)
E-138- 3
Plumb Bob (Tilt)
C-691
WheeI, Match WheeI Assy.
E-139-4
Connector
C-691-l
Wheel, Code Zapper Unit
E-139-10
"
C-693
Guide Rail. Plastic (SpeCify color)
E-140-1
"
C-694
E-146.593
"KK" Type Relay, Added Balls
C-695
E-146-695
"
C-696
"
E-148
Fuse Block, 2 lugs
C-703-1
Rocker Arm, Score Counter Units
E-148-3
Fuse Block, 6 lugs
C-704
Ratchet & Shaft. Score Counter Units
E-184-SERIES
Coil (V)
C·706
Reset Cam, Trip Relay Resets,
E-556·297
Cable, Added Balls Kits
Motorized Trip Relays
C-706-l
"
(V) See various components described in General Parts
C-706-2
"
Catalog,
commencing page 82, and Specific Parts
Data for specific games, commencing page 8.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
