PLAYFIELD·PANEL, MISCELLANEOUS PARTS
ARCH and related ports
Order by description, speci fy nome of game
BALL-GATE ASSYS.
BALL-GATE ASSY., SEE NOTE A
MS540-10-110 P-137-5
SWITCH
SEE NOTE B
BALL-GATE &SWITCH ASSY., SEE NOTE c
I COVER: SEE NOTE D I
SW-1 410
BALL-GATE & SWITCH ASSY. (A5-1315-3)
ICOVERFOR AS'1315-3: P-2996-2I
I SUPPORT BUSHING FOR AS-1315-3: S-231-6691
BUMPER SPRING
SEE POST, SPRING, PAGE 159
CARDS, Instructions and Scores
Order by port number printed on each card
GUIDE-RAIL ASSY.
I ACTUAL LENGTH 4-9/16 IN. -- •• '0 A·2898·1 0 r(
I ACTUAL LENGTH 6-1/4 IN.--.-! lil A·3054 U UI--___.J
GUIDE-RAILS, PLASTIC
(WITH 2 VERTICAL WALLS)
1-1/2 in. between hole centers: (-693
Specify Color
2-1/8 in. between hole centers: C-695
Specify Color
(WITH 1 VERTICAL WALL)
1-1/2 in. between hole centers: (-694
Specify Color
2-1/8 in. between hole centers: C-696
Specify Color
C-122 -
Specify Color
NOTES APPEAR ON PAGE 158
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
