Page 143 - Bally 1969 Parts Catalog

ROLLOYERS
WIRE
SEE NOTE A
TWO·DIRECTION ROLLOVERS
P-6254
P-6254-1
ONE-DIRECTION ROLLOVERS
Tension of Ro l l over-Sw irch blades which contact
Ac(ua(or should be adjusted (0 insure that Ball rolls
over IIc t uat or Ire e l y, without he s i(ating or sropp ing ,
M-1336-11
M-1336-12
NOTICE
Order Rollover Switches by
reference to
(A) Name of game,
(8) Function of Related Rollover.
NOTE A
Depending on applicarion, M-I336 or M-I336-10
may be used. Wires may be recognized by dimen-
sional differences indicated in reduced size
sketch below. M-1336 and M-1336-10 cannor be
used interchangeably.
~--1_13/32"-_~-;:::::::':;:::::::S-;:::::;::::::::--
"_2-5/32"
I
I
I
I
I
I
I
I
M-1336
M-1336-10
ROLLOVER BUTTONS
PAGE 151
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
150
