SWING-TYPE FREE-BALL GATES
Z·1l60
J
L-248
COIL
EE NOTE A
FREE-BALL LANE REBOUND BARRIER
SPRING
EE NOTE B
Hexagon-Head Screw
SP-403
SPRING
(NOT SHOWN)
SEE NOTE E
If Free-Ball Gate does not pull up far enough to per-
mit passage of Ball, when
"lClC"
Relay is energized,
adjust position of Relay by loosening 2 Lock-Screws
which secure Relay to Mounting Bracket and, pivot-
ing Relay Frame on Lock-Screw in tapped hole, raise
or lower end of Relay which is secured to Frame
through adjustment slot until Rei a y is in position
=~~~IF~~~~iIIIi
which permits Actuator to open Gate when Relay is c:
i:i:==~::;#\;==r=:a
energized.
HOTE It.
It part number is not listed in SPECIFIC PARTS
DATA, commencing on page 8, order pan by name,
specifying name of relay, name of game. (Whenordering
M-11l2-1
Switch or Switch Screw for relay with 2 switches, be
sure to specify LEFT or RIGHT to indicate relative
positions of switches, looked at from lug side of
switches).
M-1272-2
ISEE NOTE
.FI
Check SPECIFIC PARTS
DATA, commencing with
TRIO, page 30, for pes-
. sible vQriations,
from
game to game, in com-
ponents illustrated.
HOTE B
Sec SPRING TABLE, page
103.
HOTE C
Bracket illusttated is P-5867. Profile views of the
various Brackets and Wires associated with Swing-
Type Free-Ball Gates - and Rol l-Unders - appear
oopage~
153-155.
HOTE E
Spring SP-403
IS
not used in aU Free-Ball Gates of
type illusttated.
HOTE D
Bracleets P-6000 or P-6000-1 are used, depending on
application. P-6000-1 is dimensionally identical to
P-6000 but is Cadmium Plated ins tea d of Bright
Chrome, and one of the" holes in vertical surfaces is
.098. (Each of the " holes in vertical surfaces of
P-6000 is .062.)
HOTE F
Rebound Barrier Y-1272-2 is not used in all Free-Ball
Gates of style illustrated.
• s••
chronolOojlical Ii., 01 110m•• , page
7.
WHEN ORDERING PART
I
SPECIFY PART NO. AND NAME OF GAME
