FLIPPER-ZIPPER NOTES AND RELATED PARTS
ARM- & CAP ASSYS.
Left AS-2214-7I SEE NOTE B I
Right AS-2214-6 I SEE NOTE B I
Arm & Cap Assys. listed above are used with Flipper-
Zipper, instead of standard Assys. illustrated on page
138, and are identical to standard Assys., excepting
Flipper Arm Assy.
«Longer Shah) ••......•...... 1.-2747-4
Fastener
Screw, Shakeproof, Type 25, Self-tapping,
16 x 1/2 in., Cadmium-plated.
NOTE A
AS-2397, illustrated on page 139, and
AS-982-S88 (above) were used in
BAZAAR.
Effective with CAPERSVIllE and later
games*, check SPECIFIC PARTS DATA
for specific games, commencing page
42, under
(A) Flipper-Zipper Assy.;
(B) Switch & Bracket Assy.,
Flipper- Zipper
MOTE B
Effective with SURFERS and later garnes ", check
Specific Parts Data, commencing page 49, under
Flipper & Pin Any. for possible variations.
SWITCH & BRACKET
ASSY. AS- 982-5881 SEE NOTE A I
Bracket, Switch .........•. P-126-548
Switch SW-21O-26
Switch-Plate (spring) P-137-5
FASTENER
Switch •..........•.... M5-54O-21-510
NOTE C
E-I01-95 designates complete Magnet Assy., consist-
ing of the following components, which may be sepa-
rately purchased, if entire Assy. is not required:
Armature Assy Z-187-9
Coil. . . . . . . . . . . . . . . . .. C-2794-305
Frame Assy Z-149-K
Spring. . . . . . . . . . . . . . .. SP-1OO-189
IMPORTANT: ALSO SEE PAGE 141
FASTENERS
Order fasteners (nuts, screws, washers, erc.) by name
with reference to the part or assembly which the fas-
tener secures.
• s•• c:hronol09ical li.t of gam •• , page 7.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
