SUPER FLIPPER UNITS
ISEE NOTE
AI
ISEE NOTE
ci
RightA5-1587-19 left A5-1587-20
A-1888-12 (Right) (N)
A-1888-13 (Left) (N)
...---::-------,
ALSO SEE
PAGE 140
FLIPPER ARM & CAP ASSYS.
ISEE NOTE
BJI
SEE NOTE C
I
RightAS-2214-5 left A5-2214-4
ALSO SEE
PAGE 140
C-609-5 (LEFT)
C-610-5 (RI GHT)
SCREW-
116
x
W'
SHEET METAL TYPE
"Z"
Rubber Ring ••••••••••••••••
R-137-2
HOTE A
Standard on HARVEST and later games* (excepting
games equipped with Flipper-Zipper,
page 139) and
may be used as replacement for earlier Flipper Units.
See page 137.
HOTE
B
Standard on Harvest and later games and supplied as
replacement for A-2747. AS-2214-2.
A5-2214-
3 in all
games. (Caps C-609-5 and C-61(}-5, as well as Type
"z..
Sheet Metal Screw, can be used with either A-
2747 or A-2747-1.)
• Se. chronological Ii., of games. pog.
7.
SPECIAL KITS
K-266 (Converts A-15S7-1-4to A-1587-19)
Consists of
K-266-1, sub-assembly, consisting of
C-649 assembled to
A-1888-12 by means of 3
M5-632-4-5I 0;
A-I 889-7;
A-2747-1;
P-1637-1.
K-267 (Converts A-1587-15 to A-1587-20)
Consists of
K-267-1, sub-assembly, consisting of
C-649 assembled to
A-1888-13 by means of 3
M5-632-4-510;
A-1889-8;
A-2747-1
P-1637-1
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
138
NOTE C
Effective with SURFERS and later garnes ", check
Specific Parts Data, commencing page 49, under
Flipper
&
Pin
Assy. and
Flipper Unit
for possible
variations.
