COIN·SWITCH & REJECTOR MOUNTING ASSYS.
Consistingof Assys. and Parts illustrated on pages 59, 60
COIN-SWITCH ASSYS.,! SEE NOTE A II SEE NOTE B I
BLADE-SWITCH TYPE I SEE NOTE C I
M5-348-6-110
LJ"----.I LS-632-3-S10
SEE NOTE 0
~~---SW-100-38
P-2891-S
(Reta in ingRing)r--_--'
(NotVis ib le )
ROTOR ASY.
SEE NOTE B I SEE NOTE E I ROTOR SPRING
SEE NOTE B
When coin-mechanism is idle (before coin is depos ir ed ), Mount ing Assembly. However, av o id excessive pres-
longer blade of Coin Swiech SW-IOO-38 should rest sure of Coin Switch against pin 0 0 Rotor Assembly.
firmly aga in st pin 0 0 Rotor A s scrnb l y with ex ren s ion Coi n must pass over wi r e fr e el y and ac t u ate Coi n-
or Rotor Spr iog res rin g at borrorn 0 f Slug - Rej e cror Swi rc h.
COIN-SWITCH ASSYS., MICRO-SWITCH TYPE
ISEE NOTE A II SEE NOTE B II SEE NOTE F I
LS-632-3-510
SEE NOTE D
P-126-525--
SWITCH
SEE NOTE B
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
