PLAYFIELD·PANEL, MISCELLANEOUS PARTS
REBOUND ASSYS.
P-318-3
R-l1S-4
S-231-99
~-
BUSHING
(Not visible)
1110-24
X 3/4
in.
(HEXAGON HEAD SCREW)
REBOUND ASSEMBL Y (AS-493-3)
HOOTENANNY and later games*
-1024-1111
1110-24
x
3/4
in.
(HEXAGON-HEAD SCREW)
REBOUND ASSEM BL Y (AS·493-2)
3-IN-LI NE and earlier games*
REBOUND COVERS
(BRIGHT CHROME)
WIDTH: 3/4
in.
BETWEEN HOLE CENTERS
6 in .••.•.•.••••....••••
P-S899
6-1/4 in
P-S899·17
6-15/32 in ••.•..•.•..•.•.•
P-S899.14
WIDTH: 5/8 in.
BETWEEN HOLE CENTERS
1-1/8
in ••••••••••••• •••
P·5899-12
1.1/4
in ••.•.••••••••....
P-5899·19
1-1/2
in •.....•.•••••
.- •••
P-5899·9
1-13/16
in••.•.•.••••.••••
P-5899-5
2-1/16
in •••.•.••......•.•
P-5899-2
2·1/8
in •••.••••....•..••
P-5899-8
2-1/2
in .•.•..••.•••••.
P-5899-11
2·11/16
in ..........•....
P-5899-16
2-7/8
in •••••••••.•••••••
P-5899-6
3-3/32
in .•••••••••••••••
P-5899-3
3-1/8
in •••••••••••••••
P-5899-13
3-1/2
in. . •••••••••••••••
P-5899-7
3-9/16
in •••••••••••••••
P·5899-1
3.23/32
in ••.•.••••••• •••
P-5899-4
4-112
in •••.•.•..•.••••••
P-5899-10
RUBBER RINGS
(DIMENSIONS ARE INSIDE DIAMETERS)
5/16
in.
(11/16 in. outside diameter) ..
R-243
5/16 in. (3/4 in. outside diameter} •.•
R.402
15/32
in •••••••••• •.•..•..•••
R·392
3/4
in ••.••...•••••••• •.•••
R-137
1
in .. _ .• __ • _ . _ . _ •..
_ .. _ • _
R·135
1
in.
(Flipper Arm).
R.111.9
1·112
in
R.Ul
2
in
-
_ . R-196
2-1/2
in
- .....•
_
R-284-5
3
in
R-295-5
3-1/2 in
__ _
R-296-5
4
in •••••.• •••••••••••••
R-385-5
SW-IOO-3.66
P·137-5
TIL T-SWITCH
&
BRACKET ASSEMBLY (AS-982-460)
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
