FRONT CABINET
Playfield
(CONTINUED FROM PAGE 99)
Playlieltl
Panel Guide, *
Left. . . . . . . . . . . . • . . • . • . P-6647
Right ..•.••.••..•..•..• P-6647-1
See illustration below
ILLUSTRATED IN REDUCED SIZE
Plate & Stud Assy. * A-2901-4
See Illustration below I SEE NOTE A
Playlield
Side Rail Assy.
See Specific Parts Dato for specific gomes,
commencing with MAD WORLD, page 16,
under heading Playfjeld Panel Latch
Spinner, parts related to
See Spec i fi c Pa rts Data for spec i fi c ga mes
with Sp inner fea ture, comm enc in g with
LOOP THE LOOP, page 39
Thumper Bumper, parts related to
See pages 101, 102
Tilt Switch & Brocket Assy.
See page 124
Plastic Shield: See page 123
Post: See po ge 123
Rebound: See page 103
Relay, "KK" Type
See "KK" Type Relay
Rollover, Brackets and Wires
See pages 116, 119
Rollover Buttons: See page 117
Roll-Unders: See page 118
Rotary Flipper
See Spinner
Rubber Ring: See pages 108, 124
NOTE A
Effective with THE WIGGLER and later games·,
check Specific Parts Data for specific games under
sub-headi ng Plate & Stud Assy . for po ssible varia -
tions.
* Se e ch,on olog ;col Ii s l of qeme s , page 7.
WHEN ORDERING PART, SPECIFY PART NO. AND NAME OF GAME
