B-9414
Jet Bumper Assembly
..
I
~
I
I
I
I
I
I
....................i
.•• . .••.I
.•..•..•..1
•.......
I ....
I
.
I
.
I
.••..••.
.•.. ...,
A-941S-2
Jet Bumper Coil Assembly
Item Part Number
Description
Item Part Number
Description
1.
A-4754
Bumper Ring Assembly
1.
B-7417
Bracket
&
Stop Assembly
2.
03-6009-A5
Bumper Base, White
2.
01-1747
Coil Retaining Bracket
3.
03-6035-5
Bumper Wafer, White
3.
01-5492
Armature Link, Steel
4.
03-7443-5
Bumper Body, White
4.
01-5493
Armature Link, Bakelite
5.
10-7
Spring
5.
02-3406-1
Coil Plunger
6.
24-8776
Socket-Wedge Base
6.
10-326
Armature Spring
7.
24-8768
Bulb #555 (6.3V., 0.2SA.)
7.
AE-26-1200
Coil Assembly
8.
4006-01017-04 Mach. Screw, 6-32 x 1/4"
Associated Parts:
9.
03-7066
Coil Tubing
~
8.
A-16413
Mountain, Jet Bumper #1
03-8790
Mountain, Jet Bumper #2
03-8791
Mountain, Jet Bumper #3
WHITE WATER
2-19
