Page 144 - White Water

J1 -1
J1 - 2
J1 - 3
J1 - 4
J1 - 5
J1 - 6
J1 -7
J1 - 8
J1 - 9
J1 -10
J1 - 11
J1 - 12
J1 - 13
J1 - 14
J1 - 15
J1 - 16
J1 -17
J1 -18
J2 - 1
J2 - 2
J2 - 3
J2 - 4
J2 - 5
J2 - 6
J2 -7
J2 - 8
A-14689
Coin Door Interface Board
Interboard Wiring
11 000000000000000.00 1
1S 1100.00000 Is
J1 J2
ex> ~
0 0
0 0
0 0 • 0
0 eo LO 0 -, -,
0 0
0 0
0 •0
~ - "'I
J3 J4
1310 0 0:' 0 0 0 0 0 0 0 0 0 11 1510000000000000.011
Green-Brown (sw. col. 1) from CPU J212-1
Red-Gray (lamp row 8) from Power Driver Brd J134-9
White-Yellow (sw. row 4) from CPU J212-8
White-Orange (sw. row 3) from CPU J212-7
White-Red (sw. row 2) from CPU J212-6
White-Brown (sw. row 1) from CPU J212-4
Green-Red (sw. col. 2) from CPU J212-2
Orange-Gray (dedicated sw. row 8) from CPU J205-9
Orange-Violet (dedicated sw. row 7) from CPU J205-8
Orange-Blue (dedicated sw. row 6) from CPU J205-7
Orange-Green (dedicated sw. row 5) from CPU J205-6
Orange-Black (dedicated sw. row 3) from CPU J205-3
Orange-Red (dedicated sw. row 2) from CPU J205-2
Orange-Brown (dedicated sw. row 1) from CPU J205-1
Black (Grd) from CPU J205-10
N/C
Orange-Yellow (dedicated sw. row 4) from CPU J205-4
Orange-White (sw. enable) from CPU J205-12
J3 -1
J3 - 2
J3 -3
J3 -4
J3 -5
J3 -6
J3-7
J3 - 8
J3 -9
J3 -10
J3 -11
J3 -12
J3 -13
Violet (G.!, return) to coin door
White-Violet (G.!, 6.8VAC) to coin door
Black (Grd) to Door
Orange-Brown (dedicated sw. row 1) to coin door
N/C
Orange-Black (dedicated sw. row 3) to coin door
Orange-Green (dedicated sw. row 4) to coin door
Orange-Blue (dedicated sw. row 6) to coin door
Orange-Violet (dedicated sw. row 7) to coin door
N/C
Orange -Gray (dedicated sw.row 8) to coin door
Green-Red (sw. col. 2) to coin door
White-Brown (sw. row 1) to coin door
.
•
J4 - Not Used
.:.
J5 - Not Used
Violet (G.!, return) from Power Driver Board J119-3
Violet-White (G.!, 6.8VAC) from Power Driver Board J119-1
N/C
Gray-Yellow (+12V) from Power Driver Board J116-2
Black (Grd) from Power Driver Board J116-3
N/C
N/C
N/C
J6 - 1 White-Red (sw. row 2) to cabinet
J6 - 2 White-Orange (sw. row 3) to cabinet
J6 - 3 White-Yellow (sw. row 3) to cabinet
J6 - 4 Red-Gray (lamp row 8) to cabinet
J6-5 N/C
J6 - 6 Green-Red (sw. col 2) to cabinet
J6 -7 Green-Brown (sw. col 1) to cabinet
J6 - 8 Green-Brown (sw. col. 1) to cabinet
WHITE WATER 3-34
