RAISING THE PLAYFIELD
&'CAUTION
Do not raise the playfield straight up! This game uses a slide assembly to raise and lower the
playfield.
1. Grasp bottom arch and carefully lift up playfield only high
enough to clear safety brackets. Rear guide legs should
not hit wood guide rails or be used to slide out playfield.
To Raise Playfield:
Be sure playfieJd is in locked position and does not slide back
into the cabinet. If it does, repeat Step 2 before proceeding to
Step 3.
2. Pull the playfield out toward you until it stops (rest position) and
raise it approximately 3".
3. Rotate playfield to upright service position (lean on backbox) by
pulling toward you and up. Listen for the sound of a click; this
insures locking and pivoting sequence.
5. Push back playfield into cabinet and into playing
(2
position.
To Lower Playfield:
4. Rotate the playfield to the rest position. This unlocks
the pivoting sequence.
1-5
