A-17932
Disappearing Post Assembly
Item Part Number
Description
1 01-12441
Diverter Post Bracket
2 03-7067-5
Coil Tubing
3 01-8-508-T
Coil Retainer Bracket
4 AE-27-1200
Coil Sub-Assembly
5 10-135
Spring
6
A-17986
Bell Armature Assembly
7 23-6420
Rubber Grommet
8 4008-01 017-04 Mach. Screw, #8-32 x 1/4"
A-17796
8all Gate Actuator Assembly
Item Part Number
Description
1 01-12348
Ball Gate Coil Bracket
2 A-14406
Coil Assembly
3
A-11146
Armature Assembly
4 A-6892
Frame & Eyelet Assembly
5 10-120
Spring
6
4701-00003-00
Lockwasher #8 Split
7 4700-00089-00
Flat Washer, 11/64 x 7/16 x 16ga.
8
4008-01021-07
Mach. Screw, 8-32 x 7/16
9 10-194
Extension Spring
2-23
