U.9 08 Install Add-A-Ball
This option deletes all Free Play awards and replaces them with Extra
Ball awards. Individual adjustments are affected, as follows:
Adjustment
Name
A.1 13 Replay Boost
A.1 14 Replay Award
A.1 15 Special Award
A.1 17 Extra Ball Ticket
A.1 19 Match Feature
A.4 04 Champion Credits
A.4 05 High Score 1 Credits
A.4 06 High Score 2 Credits
A.4 08 High Score 3 Credits
A.4 07 High Score 4 Credits
New Setting
Off
Extra Ball
Extra Ball
No
Off
00
00
00
00
00
U.9 09 Install Ticket
This option deletes Credit awards and replaces them with Ticket awards.
Individual adjustments are affected, as follows:
Adjustment
Name
A.1 14 Replay Award
A.1 15 Special Award
A.1 16 Match Award
A.1 17 Extra Ball Ticket
A.1 31 Ticket Expansion Board
A.402 H.S.T.D. Award
New Setting
Ticket
Ticket
Ticket
Yes
Yes
Ticket
U.910 Install Novelty
This option removes all Free Play and Extra Ball awards.
Individual
adjustments are affected, as follows:
Adjustment
Name
A.1 04 Max. Extra Ball
A.1 05 Replay System
A.1 09 Replay Level 1
A.1 10 Replay Level 2
A.1 11 Replay Level 3
A.1 12 Replay Level 4
A.1 15 Special Award
A.1 19 Match Feature
A.4 01 Highest Score
A.4 04 Champion Credits
A.4 05 High Score 1 Credits
A.4 06 High Score 2 Credits
A.4 07 High Score 3 Credits
A.4 08 High Score 4 Credits
U.9 11 Not Used
New Setting
Off
Fixed
Off
Off
Off
Off
Points
Off
On
00
00
00
00
00
U.9 12 Serial Capture
This sets up the printer adjustments for serial transmission to a laptop
computer (9600 baud, 40 column, no page breaks, serial printer). This option requires the
installation of the optional printer kit, part number 63110.
U.913 thru U.916 Not Used
1-20
