10. Move the game into the desired location; recheck the level and pitch angle of the playfield.
11. Verify that the
required number
of balls are installed in the game. This game uses 5 balls - four are
located in the trough and 1 is a captive ball.
12 Install playfield mylars if desired.
NOTE:
This playfield has a special hardcoat surface and does not require a full protective mylar.
However, mylars can be purchased through your local Bally Distributor.
Specify part number
03-9351-1 for full playfield mylar.
13. Clean and reinstall the playfield cover glass, reversing the procedure of step 7.
14. To attach line cord, remove envelope stapled to the inside cabinet (near cashbox). Remove the four
Phillips-head screws that mount the line cord cover plate to the rear cabinet. Match the prongs on
the plug with the holes in the receptacle and push line cord securely into place. Make sure cord
aligns with the indentation of plate (indentation should point toward bottom of cabinet). Remount line
cord cover plate. If desired, tamper resistant screws are provided in an envelope marked "Security
Screws" (located in cashbox) to remount cover plate.
Receptacle
------'-
Line Cord & Plug
Tamper- resisto nt Screw
1-4
