Solenoid/Flashlamp Locations
Item Coill
Assy.
Description
No. Flasher No. Number.
01 AE-26-1500 A-19963 Ball Trough
02 20·10179
A-19778 Magnet Diverter
03 A-20099
A-19939 Trap Door Up
04 AE-26-1200 A-19939 Subway Popper
05 20·10197
Right Drain Magnet
06 AE-27-1200 A-17932 Center Loop Post
07 AE-23-800 8-10686-1 'Knocker
08 AE-27-1200 A-17932 Top Diverter Post
09 AE-27-1200 B-9362-L·3 Left Sling
10 AE-27-1200 B-9362-R-4 Right Sling
11 AE-26-1200 A-9415-2 8ottom Jet
12 AE-26-1200 A-9415-2 Middle Jet
13 AE-26-1200 A-9415-2 Top Jet
14 A-20099
A-19939 Trap Door Hold
15 A-14406
A-17796 Left Up/Down Gate
16 A-14406
A-17796 Right Up/Down Gate
17 14·8018
A-19782 Box Clockwise
18 14·8018
A-19782 Box Counter Clockwise
19
Not Used
20 24·8704
A-17983 Return Lane Flasher (2)
21 AE-27-1200 A-20003 Top Kickout
22
Not Used
23 24·8704
A-17803 Save Post Flasher
24 24·8704
A-17983 Trap Door Flasher
24·8704
A-17803
25 24·8802
24·8704
26 24·8802
24·8704 (2)
27 24·8802
24·8704 (2)
28 24·8802 (2)
24·8704
33 20·10197
34 AE-27 ·1200
35 20·10197
A-17983
A-17903
A-17803
A-17983
A-19778
A-19934
"Not Shown
Spirit Ring Flasher
Saw Flasher
Jet Flasher
Box Flasher
Cube Magnet
Sub Ball Release
Left Drain Magnet
General Illumination Circuits
Item No.Description
Bulb No.
01 String 1
#555
02 String 2
#555
03 String 3
#44
04 String 4
#44
05 String 5
#44
Flipper Coils
G.I. String 1
G.!. String 2
G.!. String 3
G.!. String 4
G.!. String 5
Coil No. Color Assy. No. Description
FL-11629 (blue) A-15849-R-2 Lower Right Flipper
FL-11629 (blue) A-15849-L-2 Lower Left Flipper
24-6549 = #44 bulb
24-8704 = #89 bulb
24-8768
=
#555 bulb
24-8802 = #906 bulb
2-45
