g. If armature and crank are to be replaced, remove the armature/crank assembly from the coils
by sliding the coils and coil brackets off of the armature. (See Fig. 14)
Fig. 14
h. To separate the crank from the armature, carefully drive out the roll pin until the crank can be
removed from the slot in the armature. The roll pin does not have to be remove~ completely
from the armature. Leaving the roll pin partially inserted in the armature will make reassembly
easier. (See Fig. 15)
Fig. 15
ROLL PIN PARTIALLY
INSERTED IN ARMATURE
1-63
