J 113 Ribbon Cable data to/from J211
J114-1 Gray-Green +12VDC to J210-7
J114-2 Gray-Green +12VDC to J904-2; J210-6
J 114-3 Gray +5VDC to J3-3 Sound Bd; J210-5
J 114-4 Gray +5VDC to J3-1 Sound Bd; J904-1; J21 0-4
J114-5 Black Ground to J3-5 Sound Bd; J904-5; J21 0-3
J114-6 Key
J114-7 Black Ground to J3-4 Sound Bd; J904-4; J210-1
J115-1 Yellow-White 6.8VAC from xfrmr secondary
J115-2 White-Borwn 6.8VAC from xfrmr secondary
J 115-3 White-Brown loop from J 115-2
J115-4 White-Orange 6.8VAC from xfrmr secondary
J115-5 White-Yellow loop from J115-6
J115-6 White-Yellow 6.8VAC from xfrmr secondary
J115-7 Orange 6.8VAC from xfrmr secondary
J 115-8 Orange 6.8V AC loop from J 115-7
J115-9 Key
J115-10 Green 6.8VAC from xfrmr secondary
J115-11 Brown S.8VAC from xfrmr secondary
J115-12 Brown 6.8VAC loop from J115-11
J11S-1 Key
J11S-2 Gray-Yellow +12VDC to playfield
J116-3 Black Ground
J11S-4 Gray +5VDC to playfield
J117-1 Key
J117-2 Gray-Yelow +12VDC to J606-S,7
J 117-3 Black Ground to J606-1 ,3
J117-4 Gray +5VDC to J606-4,5
J118-1 Key
J118-2 Gray-Yellow +12VDC to cabinet
J118-3 Black Ground
J118-4 Not Used
J119-1 White-Violet 6.8VAC G.I. to A-17051-1 J2-3
J119-2 Key
J119-3 Violet Return G.I. to A-170SH J2-S
J120-1 Not Used
J 120-2 Not Used
J120-3 Yellow Return G.I. to playfield
J120-4 Key
J120-S Green Return G.I. to playfield
J 120-6 Not Used
J 120-7 Not Used
J120-8 Not Used
J120-9 White-Yellow 6.8VAC to playfield
J120-10 White-Green S.8VAC to playfield
J120-11 Not Used
J121-1 Brown Return G.I. to insert
J121-2 Orange Return G.I. to insert
J121-3 Not Used
J121-4 Key
J121-5 Not Used
J121-6 Violet Return G.I. to insert
J121-7 White-Brown 6.8VAC to insert
J121-8 Not Used
J121-9 Not Used
J121-10 White-Green 6.8VAC to insert
J121-11 White-Violet 6.8VAC to insert
J122-1 Blue-Brown 50125 to playfield coil
J122-2 Blue-Red Sol 26 to playfield flashlamps
J122-3 Blue-Orange Sol 27 to playfield flashlamps
J122-4 Blue-Yellow Sol 28 to playfield flash lamps
J122-5 Red-Orange Tieback Diode to Sol 24 & 2S
J122-S Not Used
J122-7 Key
J 122-8 Not Used
J122-9 Not Used
J123 Not Used
J124-1 Not Used
J 124-2 Blue-Red Sol 26 to insert flash lamps
J 124-3 Blue-Orange Sol 27 to insert flashlamps
J124-4 Key
J124-S Blue-Yellow Sol 28 to insert flashlamps
J12S-1 Black-Brown Sol 17 to insert flashlamps
J 125-2 Black-Red Sol 18 to insert flash lamps
J125-3 Not Used
J125-4 Key
J 12S-5 Not Used
, J 125-6 Not Used
J 125-7 Not Used
J 12S-8 Not Used
J125-9 Not Used
J126-1 Black-Brown Sol 17 to playfield flashlamps
J 12S-2 Black-Red Sol 18 to playfield flash lamps
J126-3 Black-Orange Sol 19 to playfield motor
J126-4 Black-Yellow Sol 20 to playfield motor
J126-5 Blue-Green Sol21 to playfield flashlamps
J126-6 Blue-Black Sol 22 to playfield flashlamps
J126-7 Blue-Violet 50123 to playfield flashlamps
J12S-8 Blue-Gray Sol 24 to playfield coil
J126-9 Key
J126-10 Not Used
J126-11 Red-Orange Tieback Diode from J122-5
J126-12 Not Used
J126-13 Not Used
