SWITCH LOCATIONS (continued)
Item Switch Part
Description
Item Switch Part
Description
No. No.
No. No.
44 A-18617
Trough Ball 4 (LED)
64 5647-12073-33 Lockup Middle
A-18618
(Transistor)
65 5647-12693-32 Lockup Left
45 A-18617
Trough Ball 5 (LED)
66 5647-12693-43 Left Eject
A-18618
(Transistor)
67 5647-12133-11 Right Eject
46 A-18617
Top Trough (LED)
68 5647-12693-24 Popper
A-18618
(Transistor)
71 A-18378-6
Mini Left Standup 1
47 A-16908
Inner Loop Enter (LED)
72 A-18378-6
Mini Left Standup 2
A-16909
(Transistor)
73 A-18378-6
Mini Left Standup 3
48 5647-12693-32 Shooter
74 A-18378-6
Mini Left Standup 4
51 5647-12693-31 Wall Target Down
75 5647-12693-13 Left Ramp Left Made
52 A-1853Q-6
MO(N)GOL Target
76 5647-12693-13 Left Ramp Right Made
53 A-1853Q-6
MON(G)OL Target
77 5647-12693-13 Right Ramp Left Made
54 5647-12693-19 Left Loop Enter
78 5647-12693-13 Right Ramp Right Made
55 5647-12693-31 BatHe Drop Down
81 A-18378-6
Mini Right Standup 4
56 A-1853Q-6
Center Standup
82 A-18378-6
Mini Right Standup 3
57 5647-12693-19 Right Loop Enter
83
Not Used
58 5647-12693-13 Mini Exit Tube
84 A-18378-6
Mini Right Standup 1
61 SW-1A-114
Left Slingshot (kicker)
85 A-19666
Mini Drop Left
SW-1A-120
(score)
86 A-19666
Mini Drop Middle Left
62 SW-1A-114
Right Slingshot (kicker)
87 A-19666
Mini Drop Middle Right
SW-1A-120
(score)
88 A-19666
Mini Drop Right
63 5647-12073-34 Lockup Right
·Not Shown; ··Located under mini·playfield assembly.
2-41
