A-14615-1
1-Bank Drop Target Assembly
Item Part Number
1 03-8750-1
2 A-14617
3 4408-01119-00
4 A-11397
5 AE-26-1200
6 01-8413
7 03-7066-4
8 A-11388-2
9 4700-00072-00
10 10-392
11 20-8712-25
12 01-10183
13 4006-01003-03
14 4010-01025-14
15 10-433
16 5070-09054-00
17 5647-12693-31
18 01-8600
19 4002-01105-10
20 01-8240
21 A-14908
a) 01-8647-L
b) A-15821
c) A-14913
d) SM 1-26-600
e) 10-363
f) 4006-01003-03
g) 4700-00089-00
h) 4701-00003-00
j) 4008-01005-06
22 03-8084
23 07 -6688-17N
24 03-8630
Description
Target Flush, Yellow
Bracket & Post Assembly
Nut 8-32 ESN
Drop Target Stop Bracket
Coil Assembly
Bracket Coil Mounting
Coil Tubing
Plunger & Reset Plate Assembly
Flatwasher, 17/64 x 1/2 x 21ga.
Extension Spring
"E"-Ring, 1/4" Shaft
Switch Bracket
Mach. Screw, 6-32 x 3/16"
Mach. Screw, 10-32 x 7/8"
Extension Spring
Diode 1N4004, 1.0A
Mini Micro Switch
Insulator
Mach. Screw, 2-56 x 5/S"
Nut Plate #2-56
Target Knock Down Assembly
Actuator
Armature Sub-Assembly
Frame & Eyelet Assembly
Coil Assembly
Extension Spring
Mach. Screw, 6-32 x 3/16"
Flatwasher, 11/64 x 7/16 x 16ga.
Lockwasher, #8 Split
Mach. Screw, S-32 x 3/S"
Single Stop Target
Rivet, 5/32 x 1/8 Nickel
Guide Actuator
2-32
