A-18952
Ball Kicker Assembly
5
3
7
4
Item Part Number
Description
1 A-18816
2 01-7695
3 4006-01005-06
4 03-7568
5 A-15848-L
6 10-376
7 23-6577
8 A-14189
9 A-12390
10 03-7066-5
11 4406-01117-00
12 4006-01017-04
13 4010-01066-06
14 4701-00004-00
Bracket Sub-Assembly
Solenoid Bracket
Mach. Screw, #6-32 x 3/8"
Flipper Bushing
Crank Link Assembly
Spring
Rubber Bumper Plug
Coil Assembly
Flipper Stop Bracket Assembly
Coil Tubing
Nut #6-32 Hex.
Mach. Screw, #6-32 x 1/4"
Cap Screw, #10-32 x 3/8"
Lockwasher, #10 Split
2-22
