Kicker Arm (Slingshot) Assembly
Associated Parts for Right & Left Kickers:
!Wn I!lul
Nymber
Description
.IH.m
Pall t\!ymbt!r
Description
1.
02-2364
Coil Plunger
8.
B-9362-R-3
Coil & Bracket Assy., Left
2.
A-1781 0
Mounting Bracket Assembly
B-9362-L-2
Coil & Bracket Assy., Right
3.
A-12664
Kicker Crank Assembly
a) A-17808
Bracket & Stop Assembly
4.
12-6227
Hairpin Clip
b) 01-8-508-S
Coil Retaining Bracket
5.
4700-00030-00 Flatwasher,
17/64
x
1/2
x 15ga.
c) 4006-01 017-06 Mach. Screw, 6-32 x
3/8'
6.
03-8085
Armature link
d) 4406-01119-00 Nut, 6-32 ESN
7.
20-8716-5
Roll Pin,
1/8
x
7/16'
e) AE-26-1200
Coil Assembly
f)
03-7066
Coil Tubing
9.
10-128
Spring
