Press the Enter button to activate the Test Menu, once the menu name is shown under the Main
Menu. Then, use the Up or Downbutton to cyclethrough the Test Menu selections. Press the Enter
button to activate the desired test when that test appears in the displays.
T.TESTMENU
'£
1 Switch
Edges
'£2 Switch Levels
'£3 SingleSwitch
'£4
Solenoid 'lest
'£5
Flasher 'lest
'£6 General mllmjnation
'£7 Sound
&
Music'Thst
'£8 SingleLamps
'£9
All Lamps
'£10 Lamp
&
Flasher Tests
'£
II Display'fist
'£12 Head MotorlSwitch
'£13 Head Coils
'£14
Bead
Cycle
'£15 Helmet Light
'£16 HeadManual
Note:
Switches in
&
on the Head Assembly can be tested and adjusted
easier from Test .12 (Head Motor/Switch) on the Test Menu.
Note:
Coils
&
Motor located on the head can only be tested in T.12, T.13,
&
T.14. SolenoidTest
(TA)
will not activate the coils in the head.
Note: If
head is in error and/or unable to calibrate, see T.16 "Head Manual"
to manually control the turning
&
stopping of the head.
'£
1
Switch
Edges
For all switches, the number on the left indicates the column, the number on the right
indicates the row. Example- Switch 23 means 2nd column, 3rd row.
To test the Left and Right Flippers, press the Left or Right Flipper buttons during switch test. The
flipper name and switch number should show in the displays. Any other result indicates the
system has detected a problem with the flipper circuit.
To activate the Switch Edges 'lest, from the Test Menu, press the Enter button. The name and
number of each switch that is pressed is shown in the displays. IT any other switch, or no switch at
all is indicated, the system has detected-a problemwith the switch circuit.
Press Escape to return to the 'lest Menu. Press the Up button to display the next test, (or the Down
button to return to a previous test). Press the Enter button to activate that test.
Once the test name is shown under the 'lest Menu, press the Enter button. The name and number of
each switch that is activated is shown in the displays. This test automatically cycles through all
