Solenoid Table
THE MACHINE Solenoid Table
Sol.
Function
Solenoid
WI,..
Connections
Driver
Solenoid Part Number
No.
Type
Color
Trnstr
Flaahlamp Type
01 Outhole
High Power
Vio-Bm J13O-1
082
AE-27-1200
02 Ball Realease
High Power
Via-Red J130-2
080
AE-2S-1200
03 Under Playfield Kicker
High Power
VlO-OIn J130-4
078
AE-23-800
04 Controlled Gate
High Power
VIC-Vel
J13O-S
076
A-14406
OS Skill Shot Kicker
High Power
Vio-Grn J13O-6
064
AE-24-900
06 Wire Ball Holder
High Power
VIC-Blu J13O-7
066
AE-26-1200
07 Knocker
High Power
VIO-Blk J13O-8
068
AE-23-800
08 Head Mouth
High Power
Vio-Gry J130-9
070
AE-3O-2000
09 Upper Left Jet Bumper
Low Power
Brn-Blk J127-1
058
AE-26-1200
10 Left (sling) Kicker
Low Power
Brn-Red J127-3
056
AE-26-1500
11 Upper Right Jet Bumper
,Low Power
Brn-Om J127-4
054
AE-2S-1200
12 Right (sling) Kicker
Low Power
Brn-Vel
J127-5
052
AE-2S-1S00
13 Lower Jet Bumper
Low Power
Brn-Gm J127·6
050
AE-2S-1200
14 Jets Sling
Low Power
Brn-Blu J127-7
048
AE-26-1500
15 Head - Left Eye
Low Power
Brn-Vio J127·8
046
AE-3O-2000
16 Head - Right Eye
Low Power
Brn-Gry J127-9
044
AE~3O-2000
17 Billion Flasher
Flasher
Blk-Sm J125-1 J125-2
042
,189pfld
18 Left Ramp Flash
Flasher
Blk-Red J126-2 J125-3
040
#89 pftd, #906 Insert
19 Jackpot Flasher
Flasher
Blk-om J126-3
038
#89 pftd, #906 Insert
20 Skill Shot Flasher
Flasher
Blk-Vel
J126-4 J125-6
036
#89 pftcl
21 Left Helmet Flasher
Flasher
Blu-Gm J126-6 J125-7
028
#555 pfld, #906 Insert
22 Right Helmet Flasher
Flasher
Blu-Blk J126-7 J125-8
030
#555 pfld, #906 Insert
23 Jets Enter Flash
Flasher
Blu-VIO J126-8 J125-9
034
#555 pfld, #906 Insert
24 Left Loop Flash
Flasher
Blu-Gry J126-9
032
#555 pfld, #906 Insert
25 Helmet Ughts Data Port
Special
Blu-Sm J122-1
026
26 Helmet Ught Clock Port
Special
Blu-Red J122-2
024
A-14423-1
27 Motor Relay
Special
Blu-om J122"3
022
A-14119
28 Head Motor
Special
Blu-Vel
J122-4
020
General Hlumlnatlon Circuits
01 Backglass Body
G.I.
Wht-Sm J121-7
018
#555
02 Used In Helmet
G.I.
Wht-Org J120-8
010
#555
03 Rear Playfield
G.I.
Wht-Vel
J120-9
014
#555
04'
Backglass - No Body
G.I.
Wht-Gm J121-11
016
#555
05 Front Playfreld.
G.!.
Wht-VIO J120-11
012
#555
Lower Right Flipper
BIu-Vel
J109-7
FL-11630
Lower Left Flipper
Gry-Vel
J109-5
FL·11630
Solenoid
Table
2-42
