MENU SYSTEM OPERATION
The Main Menu allows you to choose from several options, which in turn lead to other menus to choose from. To
access the Main Menu open the coin door, press the Begin Test button, then the Enter button. Press the Up and
Down buttons to scroll through the Main Menu. To access a menu, (Bookkeeping, Printouts, etc.), from the Main
Menu, press the Enter button. To return to the Main Menu (from Bookkeeping, Printouts, etc.) press the Escape
button. Press the Start button for HELP.
MAIN MENU
B BOOKKEEPING MENU
B.l Main Audits
B.2 Earning Audits
B.3 Standard Audits
B.4 Feature Audits
B.5 Histograms
B.6 Time-Stamps
P.
PRINTOUTS MENU
P.l Earnings Data
P.2 Main Audits
P.3 Standard Audits
P.4 Feature Audits
P.5 Score Histograms
P.6 Time Histograms
P.7 Time-Stamps
P.B All Data
T.
TEST MENU
T.l
Switch E<!ges Test
T.2 Switch Levels Test
T.3 Single Switches Test
T.4 Solenoid Tes'
T.5 Flasher Test
T.6 General Illumination Test
T.7 Sound and Music Test
T.B Single Lamp Test
T.9 All Lamps Test
T.l0 Lamp and Flasher Test
T .11 Display Test
T.12 Flipper Coil Test
T.13 Ordered Lamps Test
T.14 Larnp Row-Col.
T.15 DIP Switch Test
T.iS Jump Rope Test
T.17 BoxerTest
T.18 LED Bar Test
T.19 EmQ_tyBalls Test
U.
UTILITIES MENU
U.l Clear Audits
U.2 Clear Coins
U.3 Reset H.S.T.D
U.4 Set Time and Date
U.S Custom Message
U.6 Set Game 1.0.
U.7 Factory Adjustments
U.8 Factory Resets
U.9 Presets
U.l0 Clear Credits
U.11 Auto Burn-in
A.
ADJUSTMENT MENU
A.l Standard Adjustments
A.2 Feature Adjustments
A.3 PriciQg Adjustments
A.4 H.S.T.D. Adjustments
AS Printer Adjustments
Press Escape
To move out of a menu selection.
Press Enter
To get into a menu selection.
Press Up
Increases sequence; Example A.1. A.2. A.3. AA.
Press Down
Decreases sequence; Example A4 . A3, A.2, A.1,
Use Up or Down to cycle through the selections in
a menu.
Use Escape and Enter to move into and out of the
selected menu.
