LOWER PLAYFIELD PARTS
Item Part Number
Description
1
C-13940
5 Switch
&
Diode
Assy.
2
A-14977
7 Opto PCB Switch Assy.
3 01-10427
Diverter Support Bracket
A-14185
Drive Arm Assembly
A-15040
Diverter Assembly
A-13278
Plunger Assembly
10-437
Kicker Spring, Heavy
4
A-94 I 5-2
Jet Bumper Coil Assy. (5)
B-12030-2
Switch
&
Diode
Assy. (5)
A-12753-2
Lug
&
Diode Assembly (5)
5
A-14962
Loop Assembly
6
A-15115
Kicker Assembly
7
A-15205-L-l
Flipper Assembly
8
01-9510
Post Adj. Plate #8 (2)
9
A-I 4369-L
Coil
&
Bracket
Assy.
B-8284-1
Kicker Count Switch Assy.
B-12665
Nylon Kicker Assembly
10-128
Spring
\ 10 A-15205-L-4
Flipper Assembly
11 A-15139
Hi-Powered PCB Assy.
12 B-8925
Micro Switch Plate Assy.
13 B-9362-L-2
Coil
&
Bracket Assy.
10-128
Spring
C-9638
Outhole Eject
Assy.
14 A-15205-R-4
Flipper Assembly
15 A-14369-L
Coil
&
Bracket
Assy.
A-11539-1
Kicker Switch Assy.
B-12665
Nylon Kicker Assembly
10-128
Spring
16 A-15367
Knockoff Assembly
17 A-14107
Kicker Assembly
18 A-14964
Lock-up Loop Assembly
19 20-9247 (3)
Coil Magnet
20 A-I 5257 (3)
Brkt.
&
Pole Piece Assy.
21 01-10446
Swamp Bracket
22 A-15205-R
Flipper Assembly
23 A-I 5070
Chute Ramp Assy.
24 A-15200
Kickout Assembly
25 A-15368
Eject Assembly
A-9381-R
Switch
&
Bracket Assy.
26 A-14711
Hand Drive Assembly
27 A-14703
Box Assembly
28 A-14970
Bookcase Assembly
Not Shown:
A-14632-3
3/4"
Meg. Brkr, Clamp Assy.
A-14632-4
I" Mtg. Brkt. ClampAssy.
A-15340
Motor EMI Board w/Brake
01-8726- L-l
Playfield Holder Brkt., Left
01-8726-R-I
Playfield Holder Brkt., Right
5731-09651-00
Fuse
5733-10702-01
Fuse Holder
Underside of Playfield, Viewed in Raised Position
The ADDAMS FAMILY 2~38
