Unique Parts
part Number
Description
part Number
Description
A·12738·20017 WPC Sound Board
A·15247
Ball Guide Assembly
A·12742·20017 WPC CPU Board
A·15248
Ball Guide Assembly
A·13204·200 17 Bottom Arch Assembly
A·15249
Ball Guide Assembly
A·13767·20017 Backbox Assembly
A·15250
Ball Guide Assembly
A·13769·20017 Playfield
&
Insert Assembly
A·15251
Ball Guide Assembly
A·14073
Box Assembly
A·15257
Bracket
&
Pole Piece Assy.
A·14711
Hand Drive Assembly
A·15258
Chair Bracket Assembly
A·14962
Loop Assembly
A·15267
Knocker Assembly
A·14970
Bookcase Assembly
A·15280
Single Flashlamp Assembly
A·14972
X-Over Ramp Wire Chute Assy.
A·15285
2·Switch Opto PC Board
A·14973
Shooter Ramp Assy.
A·15310
Interrupter Assembly
A·14974
Ball Guide Assy . Shooter Ramp
A·15340
Motor EMI Board
A·14977
7-Opto PC Board
A·15367
Knockoff Assembly
A·15017
4·0pto PC Board
A·15368
Eject Assembly
A·15040
Diverter Assembly
A·15369·1
Playfield Plastic Assembly
A·15070
Chute Assembly
A·15369-2
Playfield Plastic Assembly
A·15110
to-tamp
Board
A·15369·3
Playfield Plastic Assembly
A·15111
a-Lamp Board
A-15375
Cloud Assembly
A·15112
5-Lamp Board
A·15416
Extra Flipper Supply Board
A-15113
4-Lamp Board
A-15114
4-Lamp Board
02-4611-1
M·F 8·32 x
3-112
Hex. Standoff
A·15115
Kicker Assembly
A·15139
High Power PC Board
A-15158·1
Cashbox Assembly
03-8651·13
Jet Bumper Cap· Clear
A-15197
Opto Ball Guide Assembly
03·8643
Cloud
A-15199
Opto Ball Guide Assembly
03-8644
Hand
A-15200
Kickout Assembly
03-8647
Electric Chair
A·15205·L·l
Flipper Assembly
A-15205-L ·4
Flipper Assembly
A·15205-R·4
Flipper Assembly
10-437
Kicker Spring
A·15212
Speaker Display Assembly
A·15239
Ball Guide Assembly
A·15240
Ball Guide Assembly
23·6674
Bumper Pad: 7/8 x 5/16
A·15241
Ball Guide Assembly
A-15242
Ball Guide Assembly
31-1002-20017 Screened Playfield
A-15243
Ball Guide Assembly
31·1008·20017 Screened Bottom Arch
A-15244
Ball Guide Assembly
31-1009-20017 Screened Shooter Gauge
A-15245
Ball Guide Assembly
31·1357-20017 Screened Transl~e
A-15246
Ball Guide Assembly
31·1420·20017 Screened Spkr. Panel Cover
The
ADDAMS
FAMILY 2-33
