A-14970 Bookcase Assembly
Item Part Number
Description
Qty.
01-10398
Mounting Bracket
2
14-7969
Motor, Bookcase
1
3
01-10399
Switch Bracket
2
4
5647-12693-08
Mini Micro Switch
2
5
5070-09054-00
Diode 1N4004 1.0A
2
6
01-8240
Nut Plate #2-56
2
7
4002-01105-07
MS 2-56 x 7/16 P-PH-S
4
8
4008-01005-10
MS 8-32 x 5/8 P-PH
4
9
03-8619
Crank, Bookcase
1
10
03-8620
Actuator, Bookcase
1
11
4108-01031-14
SMS #8 x 7/8 P-TH-Type 25
2
12
4700-00016-00
FW .187 x .437 x
.053
5
13
20-8716-2
Rollpin 3/32 x 5/8
1
14
07-6688-18N
Rivet 3/16 x
118
Nickel
4
15
02-4003
Bumper Post 8·32
4
16
23-6535
Rubber Bumper
4
17
03-7655-4
Harness Clip 1/4
2
18
4408-01119-00
Nut 8-32 ESN
5
19
4106-01004-10
SMS #6 x 5/8 P-PH-ST
2
20
A-15018
4 Infra Red LED Assembly
1
21
03-8623
Base, Bookcase
1
22
03-8622
Frame, Bookcase
1
23
03-8621
Cover, Bookcase
1
24
31-1664-25
Screened Playfield Plastic
1
25
H-15229
Cable Assembly, Bookcase
1
26
23-6674
Bumper Pad 1-1/8 x
2-5/16
1
27
07-6688-20N
Rivet 1/4 x
1/8
Nickel
2
28
4700-00003-00
FW .125 x .281 x .032
2
29
03-8624
Lens, Bookcase
4
30
A-15017
4 Opto PCB Assembly
1
31
4106-01004-06
SMS #6 x 3/8 P-PH-ST
2
32
4108-01004-06
SMS #8 x 3/8 P-PH-ST
3
33
02-4419
Adjusting Screw
1
34
02-4418
Shaft,2-1/2
1
35
03-8347
Gland
1
36
20-9610
Flange Bearing
2
37
03-8363
Locking Nut
1
38
4008-01157 -10
MS 8-32 x 5/8 P-PH-S-Ny
1
39
4008-01017 -08
MS 8-32 x 1/2 P-PH-S
1
40
H-15227
Bookcase Switch Cable
1
41
4700-00070-00
FW .187 x .625 x .059
2
42
4008-01157 -08
MS 8-32 x 1/2 P-PH-S-Ny
The ADDAMS FAMILY 2-28
