A-1S20S-R
Flipper Assembly·
Upper Right
Flipper Assembly Notes ...
nem Part Number
Description
1. Each Flipper Assembly on the lower Play1ield is
mounted beneath the playfield, in conjunction with
1.
B-13104-R
Flipper Base Assy, Right
the plastic Flipper Paddle and Shaft (20-9250-6)
2.
SW-1A-193
End of Stroke (EOS) Sw.
and Flipper Rubber (23-6519-4) on the upper side
3.
4701-00002-00
lockwasher, #6 Split
of the playfield.
4.
4105-01019-10
Sh. Metal Screw,#5 x 5/8
2. The tip of the EOS Switch must travel
5.
4008-01079-05
Mach. Screw, 8-32 x
5/16
0.150
(+
.010, - .000) inch, before the contacts fully
6.
4701-00003-00
lockwasher, #8 Split
open, with the flipper in the actuated position.
7.
01-9375
Switch Mounting Bracket
The EOS Switch contacts must have a gap of
8.
20-6516
Speednut, Tinnerman
0.062 (± .015) inch. Adjustment of the EOS Switch
9.
401 0-01 066-06 Cap Screw, 10-32 x
3/8,
SH
must be made at a minimum distance of 0.25 inch
10.
4701-00004-00
lockwasher, #10 Split
from the switch body.
11.
A-12111
Flipper Stop Assembly
3. All moving elements of the assembly must operate
12.
FL-11630
Flipper Coil - Red
freely, with no evidence of binding.
a)
•••
Coil Tubing
4. For coil replacement, remove the Solenoid Bracket
13.
01-7695
Solenoid Bracket
(Item 13) to prevent screw damage.
14.
4006-01017-04
Mach. Screw, 6-32 x
1/4
5. Use loctite™ 242 when reattaching screws to the
15.
10-364
Spring
Flipper Stop Assembly, the Solenoid Bracket, and
16.
B-13882-R
Crank link Assembly, Right
the Flipper Bushing.
17.
23-6577
Bumper Plug
6. When replacing their Bumper Plug (item 17) to
18.
03-7568
Flipper Bushing
restore proper flipper operation, readjust the flipper
19.
4006-01005-06
Mach. Screw, 6-32 x
3/8
paddle and shaft position.
20.
4406-01117 -00 Nut, 6-32 Hex.
7. Solid-color blue wire connects to the banded end
of each diode, mounted on the connector end of the
Associated Parts:
Flipper Coil (item 12). Trace-color wire connects to
23-6519-4
Flipper Rubber, Red
the unbanded end of the diode.
20-9250-6
Flipper & Shaft, Yellow
8. "'. Not available for individual
sale
A-1S205-L-1
Flipper Assembly -
Upper Left
(Parts listed replace same items of A·1S20S·R)
A·15205·L·4
Flipper Assembly ..
Lower Left
(Parts listed replace same items of A·1520S·R)
Item Part Number
Description
Item Part Number
Description
1.
B-13104-L
12.
FL-11753
16.
B-13882-L
Flipper Base Assy, left
Flipper Coil
Crank link Assembly, left
1.
B-13104-l
12.
Fl-15411
16.
B-13882·l
Flipper Base Assy, Left
Flipper Coil - Orange
Crank Link Assembly, left
Associated Parts:
23·6553·4
20-9264-6
Small Flipper Rubber, Red
Small Flipper & Shaft
0)
A-15205 ..R·4
Flipper Assembly -
Lower Right
(Parts listed replace same items of A·1S20S·R)
A·106S6 Flipper Link
Item Part Number
Description
12.
Fl-15411
Flipper Coil - Orange
The ADDAMS FAMILY 2-16
