GAME OPERATION
III
CAUTION
After assembly and installation at the site location, this game must be plugged into a properly
grounded outlet to prevent shock hazard, and to assure proper game operation. DO NOT use a
'cheater' plug to defeat the ground pin on the line cord. DO NOT cut off the ground pin.
POWERING UP. With the coin door dosed. plug the game in and switch it On. using the On-
Off Switch. In normal operation, Testing will show in the display as the game performs Start-
Up Tests.
Once the Start-Up Tests have been successfully completed the last score is
displayed. Afterward, the game goes into the Attract Mode (playfield and backbox lamps
flashing, sounds heard. etc., if the operator does not change the Factory Setting).
Note:
After the game has been on location for a period of time, the Start-Up Tests may
contain messages concerning game problems. The section entided 'Problem Analysis Messages'
contains more detail concerning messages displayed at each game
turn-on.
Open the coin door and press the Begin Test Switch. The display shows the game name, game
number and game software revision. The message changes. The display shows the sound
software revision, revision level of the system software and date the game software was revised.
Example:
THE ADDAMS FAMILY
20017 Rev. L-I
Sound Rev. L-l
Sy.2.12
7/15/91
Press the Enter button to enter the WPC Menu System (refer to the section entitled 'Menu
System Operation'
for more information). Perform the ~ Test Menu routine to verify the
game is operating satisfactorily. Successful completion of the tests in the Test Menu rourine
will show the game is ready to begin earning your investment return.
ATTRACT MODE*.
After completing the Test Menu routine. press the Escape button three
times to enter the Attract Mode.
During the Attract Mode. playfield and backbox lamps
blink. The display exhibits a series of messages informing the player concerning:
A. Recent highest scores"
B. A "custom message"
C. The score to achieve to obtain a Replay award*
These (or similar) displays reappear occasionally, accompanied by sounds and music. until a
player initiates game play by inserting a coin, or when credits are available. pressing the Start
button.
"Operator-adjustable feature.
The ADDAMS FAMILY 1-5
