Dis~lay Circuits
Emmi
Erom:
WI[I
~212[
Euncti2n
ill
~~U
Bd. S2YDd
Bd.
Ribbon Cable Data
J601
J202
J500
Ribbon Cable Data
J602
201
Ribbon Cable Data
J603 To/From Dot Matrix DisplaylDriver Board
Connector to Dot Matrix DisplaylDriver
Orange
-125V
J604-1
Blue
-113V
J604-2
Black
Ground
J604-4
Black
Ground
J604-5
Gray
+5V
J604-6
GrayfYellow +12V
J604-7
Brown
+62V
J604-8
Connector to Transformer (AC)
White
80VAC
J605-1
White
80VAC
J605-2
Violet
100VAC
J605-3
Violet
100VAC
J605-5
Connector From Power Driver Board
Black
Ground
J606-1
Black
Ground
J606-3
Gray
+5V
J606-4
Gray
+5V
J606-5
GrayNellow·
+12V
J606-6
GrayNellow +12V
J606-7
Sound Circuits
Wire C21o[
Function
Ribbon Cable Data
J506 ToIFrom CPU Board, Flipper Board
&
Dot
Matrix Controller
Connector From Transformer Secondary
Gray/Green +12VDC
J501-1
Gray/Green +12VDC
J501-2
Gray
+5VDC
J501-4
Gray
+5VDC
J501-5
GraylWhite -12VDC
J501-6
GraYlWhite -12VDC
J501-7
Power From CPU/Power Driver Board
Gray
+5VDC
J502-1
Gmv
+5VDC
J502-3
Black
Ground
J502-4
Black
Ground
J502-5
Cabinet Speaker Connection
BlacklYellow Speaker
J504-2
Backbox Speaker Connection
BlacklYellow Speaker
J505-3
The ADDAMS FAMILY 3-20
