CONNECTOR
&
COMPONENT IDENTIFICATION
Each plug or jack receives a number that identifies the circuit board and position on that
board that it connects to. J -designations refer to the male part of a connector.
P-
designations refer to the female part of a connector. For example. JIOI designates jack 1
of board
1
(a Power Driver Board Board jack); P206 designates plug 6 of board 2 (a CPU
Board plug). Identifying the specific pin number of a connector involves a hyphen. which
separates the pin number from the plug or jack designation. For example. J 101-3 refers to
pin 3 of jack
1
on board
1.
Other game components may also have similar numbers
to
clarify their locations or
related circuits. For example. FSOI refers to a fuse located on the Sound Board.
Prefix numbers for the WPC circuit boards are listed below.
1-
Power Driver Board
2- CPU Board
5- Sound Board
6- Dot Matrix Controller
Dot Matrix Display/Driver Board
8 - Flipper Controller Board
9 - Extra Flipper Supply Board
The ADDAMS FAMILY 3-1
