PINBALL GAME ASSEMBLY INSTRUCTIONS
1. Open the shipping container; remove all cartons, parts, and other items, and set them aside.
2. Place cabinet on a support and attach rear legs (after installing leg levellers), using leg bolts. Leg
levellers and leg bolts are both provided among the parts in the cash box.
3. Attach the front legs (after installing leg levellers), using leg bolts. See Figure 3 for details.
,
--.
,
'
,
,
- ---
•••
o.
_
;.: 0 degrees
Approx
Playfield
Pilch
Angle:
6 degrees
~
..
~: :.':: ::: rc : : ::: :::::::::::
.-::::: ••:::.: •••• ~.
m-----'~
Leg Leveller
Shaft
Leg
.....--See
Detail View
____ Nut
e:::;;;;;;~-
Leveller
FootPad
Detail View -
Leg Leveller
Figure 3. Pinball Assembly, Playfield Pitch Angle, and Leg Leveller Details.
4.
Reach into the cabinet and backbox and check the mating of the interconnecting cables, match-
ing several wire colors at each connector. Ensure that all connections are properly secure.
(Q';&tJ:Ju©1M
Ensure that the interconnecting cables are free to move (not kinked or pinched).
Be
careful not to damage wires at any stage of the assembly process.
5.
Raise the hinged backbox upright and stabilize it into position, using the clamp on the back of the
cabinet and backbox. Unlock the backbox, and remove the backbox glass, storing it carefully to
avoid scratches. Remove the shipping block holding the Insert Board. Unlatch the Insert Board
and open it, then lift the SpeakerlDisplay Panel up and lay it forward on the playfield cabinet. This
allows access to the bolt holes used for securing the backbox upright. Install the mounting bolts
and flat washers through the bottom holes of the backbox into the threaded fasteners in the
cabinet to secure the backbox.
( WA.RNING
J
NEVER
transport a pinball game with the hinged back box erect.
Always
lower
the backbox forward onto the playfield cabinet on a layer of protective material
to prevent marring or damage and possible personal injury.
6.
Extend each leg leveller
slightly
below the leg bottom, so that all four foot pads are extended
about the same distance.
Remove the cabinet from its support and place it on the floor.
TAXI 5
-------
- - - ------
- -- - --
