Solenoids/Flashers
Item Part No.
DescrIption
01A AE-23-800
Outhole Kicker
01C #89 Flashlamps
PIN·BOT (p,i) Flashers
02A AE-23-800
Ball Shooter Lane Feeder
02C #89 Flashlamps
Dracula (p,i) Flashers
03A AL-23-800
Catapult
03C #89 Flashlamps
Marilyn (p,i) Flashers
04A AE-26-1200
Middle 3-8ank Drop Target
04C #89 Flashlamps
Santa (p,i) Flashers
05A AE-23-800
Top Eject Hole
05C #89 Flashlamps
Gorbie (p,i) Flashers
06A AE-26-1200
Right 3-8ank Drop Target
06C #89/906 Flashlamps Left Ramp (p,d) Flasher
07A AE-26-1500
Spinout Kickbig
07C #89/906 Flashlamps Right Ramp (p,d) Flasher
08A AE-26-1500
Right Lock (Eject Hole)
08C #89 Flashlamps
Spinout (p) Flasher
09 SM-1-35-4000-DC Top 8all Gate
10 5580-12145-01
Insert BelGen Illumin Relay·
11 5580-12145-01
PlayfieldGen Illumin Relay·
12 5580-09555-01
Solenoid
NC
Select Relay"
13 SM-26-600-DC Bell
14 AE-26-1200
KnockerlTicket Dispenser (b)
15 #89 Flashlamps
JACKPOT (p,i) Flashers
16 #89 Flashlamp
JOYRIDE (p) Flasher
17 AE-23-800
Left Jet Bumper
18 AE-26-1500
Left Kicker ("Sling")
19 AE-23-800
Right Jet Bumper
20 AE-26-1500
Right Kicker ("Sling")
21 AE-23-800
Lower Jet Bumper
22 Not Used
FL 11630/S0VDC Lower Left and Right Flipper
• - On Relay Board, C-11998-1, on Playfield and Insert Board
•• - In backbox on Aux Power Driver Bd, 0-12247
Rubber Parts
Part No. Description Qty
Part No. Description
Qty
23-6300 5/16" Ring
11
23-6313-1 Grommet
1
23-6301 3/4" Ring
1
23-6327 Ball Shooter Tip
1
23-6302 1" Ring
2
23-6519-4 Lg Red Flipper Ring
2
23-6303 1-1/4" Ring
1
23-6535 Bumper
7
23-6304
1-1/2"
Ring
1
23-6552 Sleeving, Black
7
23-6305 2" Ring
1
23-6556 Sleeving, Black
1
23-6306
2-1/2"
Ring
3
23-6626 Grommet
6
23-6310 5" Ring
1
- r>
TAXI 57
- - ----- - -- - -
------
-- - -
-- ---
--
- - -
