Power Supply
pIn 0-12246
Item Part No.
Ckt Designator
Description
Item Part No.
Ckt Designator
Description
1 5765-12317-00
Power Supply PCB
25 5075-09059-00
ZR1. ZR3
Zener, 1N5990, 3.911, 5%
2 5733-12060-01
Fl-F5
Fuse Holder
26 5075-09060·00
ZR2, ZR4
Zener, 1N4764. 10011,5%
3 5731·09432-00
F6,F5
Fuse,7A,250V,S·B
27 5460·09424·00
ICI
IC, Volt, Reg., MCI723C5
4 5731-12328-00
F1
Fuse, 31Bk, 250V, S·B
2B 5010-09069·00
R3.R6
Resistor, 330K, 5%,
1/2w,
C.F.
5 5730-12327-00
F2.F3
Fuse liB A., 250V
29 5010-09061-00
R2.R5
Resistor, 680n, 2w
6 5791-10862-15
Jl
l5H STR SO. PIN .156
30 5010-09536-00
AI, R4
Resistor, 39K, 5%,1w
7 5791-10862-06
J2
6H STR SO. PIN .156
31 5013·09426·00
R7
Resistor. 2.15K, 1%, 114w, C. F.
8 579",
0862-09
J3
9H STR SO. PIN .156
32 5013·09427-00
R8
Resistor. 4.99K, 1%, ll4w, C. F.
9 5100-09690-00
BRl
Bridge Rectifier. 35A., 200V
33 5010-09541-00
R9
Resistor, 2.7K,
2%,1/4w.
C. F.
10 5164-12154-00
01
Transistor, MJE15030, NPN
34 5010-09085·00
Rl0
Resistor. 1.5K, 5%.114w. C. F.
11 5194-12155-00
03
Transistor, MJE15031, PNP
35 5010-09428·00
Rl1
Resistor, 1.SK, 2%,
1/4w,
C. F.
12 51 94·09055·00
02
Transistor, MPS052, PNP
36 5010-09508-00
R12
Resistor, 270n, 2%.
1/4w.
C. F
13 5164-09056-00
04
Transistor. MPS002, NPN
37 5012-09429·00
R13
Resistor. 0.12n, 5%.5w
14 5162·09425-00
05
Transistor, 2N6057. NPN
38 5040-12324·00
Cl,C3
Capacitor, 150 mid, 160v, radial
15 5701-09652·00
Mica Insulator
39 5043-09072-00
C2,C4
Capacitor, 0.1 mid, 500v, disc
16 4006-01003·06
Mach, Screw, 6·32 x 318
40 5040-09421-00
C7
Capacitor. 100 mid, 25v, radial
17 4006·01003-08
Mach. Screw. 6-32 x 112
41 5040·09422-00
C8
Capacitor, 47 mid, 50v. radial
18 20·9229
Thermal Compound
42 5040-09420·00
C9
Capacitor, 1000 mid. electr.
19 4406-01117·00
Nut. 6-32 Hex.
5040-08893-00
25v, axial or radial
20 5010·09534·00
WI
Resistor,On
43 5040-0941 9·00
Cl0
Capacitor. 18,000 mid, electr,
21 4703·00007·00
Lockwasher, #6 Ext.
2Ov, axial
22 570S·12330-00
Heatsink 4"
44 5040·09423·00
C12
Capacitor, 330 mid, electr,
23 5705-09199-00
Heatsinx 6030B
10v,radial
24 5070·09054·00
01, D3-C6
Diode, 1N4004
45 5043-09446-00
C14
Capacitor, 0.1 mfd,
SOli.
disc
46 5043-09065·00
C15
Capacitor. 470 pfd
47 5824·0942B-00
TP1. TP3, TP4 Terminal, #1502-1 (Test Post)
.r>:
NOTES:
L
Heat sink compound must be applied between transistor and heat sink.
2.
Observe index mark on integrated circuit, polarity of capacitors and
diodes, and position of transistors.
TAXI 39
