A·15849-R·2
&
A·15849-L·2
Flipper Assembly
bIm
part Number
Description
1.
B-13104-R
Flipper Base Assy., Right
B-13104-L
Flipper Base Assy., Left
2.
SW-1A-194
Switch Assembly
3.
4701-00002-00 Lockwasher, #6 Split
4.
4105-01019-10 Sh. Metal Screw, #5 x 5/8 P-RH-A
5.
4008-01079-05 Mach. Screw, 8-32 x
5116
H-SOC
6.
4701-00003-00 lockwasher, #8 Split
7.
01-9375
Switch Mounting Bracket
8.
20-6516
Speednut, Tinnerman
9.
4010-01066-06 Cap Screw, 10-32
X
3/8, SH
10.
4701-00004-00 lockwasher, #10 Split
11.
A-12390
Flipper Stop Assembly
12.
FL-11629
Flipper Coil (Blue)
a) 03-7066-5
Coil Tubing
13.
01-7695
Solenoid Bracket
14.
4006-01017-04 Mach. Screw, 6-32 x 1/4 P-RH-S
15.
10-364
Spring
16.
A-15848-R
Crank Link Assembly, Right
A-15848-L
Crank Link Assembly, Left
a)
A-17050-R
Flipper Crank Assembly, Right
A-17050-L
Flipper Crank Assembly, Left
b) A-15847
Flipper link Assembly
c) 02-4676
Link Spacer Bushing
d)
4010-01086-14 Cap Screw, 10-32 x 7/8 SH
e) 4700-00023-00 Flatwasher,
5/8
x 13/64 x 16ga.
f) 4701-00004-00 Lockwasher #1 0 Split
g) 4410-01132-00 Nut, 10-32 ESN
17.
23-6577
Bumper Plug, SIS"
18.
03-7568
Flipper Bushing
19.
4006-01005-06 Mach. Screw, 6-32 x 3/S P-PH
20.
4406-01117-00 Nut, 6-32 Hex
• Associated Parts for Left
&
Right flippers:
21.
23-6695
22.
20-9250-5
Flipper Rubber Ring,
1-1/2"
(3 Used)
Flipper
&
Shaft-White (3 Used)
